Image preview - the first page of the document
>> Download fc9172 documenatation <<
Text preview - extract from the document
Vacuum cleaner
FC9172
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION ACCESSORIES
- This product meets the requirements regarding - Nozzle : Tri-Active all purpose nozzle
interference suppression on radio and TV. - Special Nozzle : Super Parquet Nozzle
- After the product has been repaired, it should function - Tubes : Metal lacquered 3-piece telescopic tube
properly and has to meet the safety requirements as - Accessories : Brush, crevice nozzle and small nozzle
officially laid down at this moment.
- Accessory storage : Active accessory storage bridge in
handgrip
TECHNICAL INFORMATION - Coupling : Button coupling
- Colour : Cardinal Red
- Power consumption : 2000 W OPTIONAL (accessories)
(IEC) 230V
- FC8021 : S-bag Classic
- Maximum Air displacement : 47 l/s
- FC8022 : S-bag Clinic
- Vacuum : 340 mbar / 34.0 kPa
- FC8023 : S-bag Anti-Odour
- Type number dustbag : FC8023
- FC8031 : Super Clean Air HEPA filter,
- Duststorage capacity : 4L HEPA12 exhaust filter
- Cord length : 9m - FC8038 : Ultra clean air washable HEPA13
- Fiter system : Classic S-Bag exhaust filter
long performance
: 3 layer permanent motor
protection filter
: Ultra clean air washable
HEPA13 exhaust filter
- Dimensions of cleaner : 472 x 324 x 276 mm
- Dimensions of packaging : 593 x 393 x 296 mm
- Net weight : 6.3 kg
