Image preview - the first page of the document
>> Download service_manual_3p61_100 documenatation <<
Text preview - extract from the document
Colour television Chassis
3P61
Contents Page
1. Technical Specifications, Connections, and Chassis
Overview 1-3
4. Mechanical Instructions 4
5. Circuit Diagrams and PWB Layouts 5-10
6. IC data sheet 11-16
EN 1 1. SK4.0A CA Technical Specifications, Connections, and Chassis Overview
1. Technical Specifications, Connections,and Chassis Overview
Index of this chapter
Technical Specifications
Connection Overview
Chassis Overview
Note: Data below can deviate slightly from the actual situation, due to the different set executions.
1.1.Technical Specifications
Target
29" 21"
Skyworth Proposed Chassis Philips 6P19S Philips 3P61S
Specifications Chassis Specifications Chassis
29PT8867/93 21PT8867/93
TV Model
29PT8857/93 21PT8857/93
29PT8867/93 - 28K 21PT8867/93 - 10K
2007 Volume
29PT8857/93 - 33K 21PT8857/93 - 26K
Production Center Skyworth Gongming Skyworth Gongming Skyworth Gongming Skyworth Gongming
y g
Deliver Confi uration Complete Build Up (CBU) CBU Complete Build Up (CBU) CBU
CR Date June-07 June-07
CRT size 29" RF Slim Yes 21" RF Slim Yes
Type HD Ready (1080i/720p), 100Hz Yes Analog 50Hz Yes
2 tone black (speaker black) 2 tone black (speaker black)
Styling (SL7) Yes Yes
2 tone silver (speaker silver) 2 tone silver (speaker silver)
TV Systems PAL multi (NTSC playback) Yes PAL multi (NTSC playback) Yes
Sound Systems DKI Yes DKI Yes
Language Simplified Chinese, English Yes Simplified Chinese, English Yes
Power supply 160Vac ~ 260Vac 50Hz Yes 160Vac ~ 260Vac 50Hz Yes
Standby Power <3W Yes <3W Yes
Channel 200 channel Yes 200 channel (stored) Yes
Audio Output 2X6W, AV Stereo Yes 2X3W, AV Stereo Yes
Tuner FS tuner Yes FS tuner Yes
CRT Superslim China Yes Ultraslim Yes
Black Level
Yes Yes Yes
Expansion Yes
Comb filter for NTSC [Built-in Comb filter for NTSC [Built-in
Comb filter Main IC] Main IC]
Comb filter for PAL/NTSC Yes Comb filter for PAL/NTSC No
Smart Picture Yes Yes Yes Yes
Color Temperature: Cool, Color Temperature: Cool,
Picture Color Temp
Warm,Normal Yes Warm,Normal Yes
SVM Yes Yes No No
Pic Rotation Yes Yes Yes No
Pic Mode Picture Mode: 4:3 16:9 Yes Picture Mode: 4:3 16:9 No
LTI/CTI Yes Yes No No
DNR Yes Yes Yes No
Sharpness ?? Yes Yes Yes Yes
AV Stereo Yes Yes Yes Yes
Dolb Virtual
y No No No No
Balance Balance Yes Balance No
Automatic Vol
Control Automatic Volume Control Yes Automatic Volume Control No
Smart Sound Yes Yes Yes No
Sound
Loudness Loudness No Loudness No
Global Nicam & A2 (German Global Nicam & A2 (German
Nicam/A2
Stereo) No Stereo) No
Bass/Treble Control
Bass/Treble Control (Build-in) No Bass/Treble Control (Build-in) No
Graphic E.Q Graphic E.Q.(Build-in) Yes Graphic E.Q.(Build-in) No
Teletext N.A No N. A No
In TV mode, No signal auto In TV mode, No signal auto
Auto Stdby
standy in 15 minutes. Yes standy in 15 minutes. Yes
On/Off Timer On/Off Timer Yes On/Off Timer Yes
Sleep Timer Sleep Timer Yes Sleep Timer Yes
Game Game No Game No
Calendar Calendar No Calendar No
Features
Notebook Notebook No Notebook No
Favorite Channel Favorite Channel No Favorite Channel No
Channel Skip Channel Skip Yes Channel Skip Yes
Child Lock Child Lock Yes (lock via local keysonly) Child Lock Yes
(lock via local keys only)
Parental Guide Parent Guide No Parent Guide No
Channel Swap Channel Swa p No Channel Swa p Yes
F t Nil N Nil N
Technical Specifications, Connections, and Chassis Overview SK4.0A CA 1. EN 2
Front Nil No Nil No
Connectivity Side AVin, SVHS Yes Avin Yes
Rear AVin, Avout, YPbPr, CVI Yes CVI, AVin, Avout,SVHS Yes
Micro-processor UOC 3 Hercules Yes UOC 2 Yes
Lead-free status Yes Yes Yes Yes
Non-flammable Mains Elcap Yes Yes Yes Yes
Plastic Resin Yes HB Yes HB
ROHS Compliance Yes Yes Yes
BSD Compliance Yes Yes Yes
Safet Compliance
y CCC Yes CCC Yes
Menu OSD New UI To propose new UI New UI To propose new UI
250*330 250*330
Chassis outline (dimension) 250*130; Scan Board: 250*200;>
Remote control Racer (Chinese text) Racer (Chinese text) Racer (Chinese text) Racer (Chinese text)
1.2.Connection Overview
EN 3 1. SK4.0A CA Technical Specifications, Connections, and Chassis Overview
1.3. ChassisOverview
CRT PANEL
MAIN POWER SUPPLY
CHASSIS
PANEL LINE DEFLECTION
FRAME DEFLECTION
TUNER IF
AV I/O
AUDIO / VIDEO
VIDEO IF SOUND IF
CPU CONTROL
AUDIO AMPLIFIER
EN 4 2. SK4.0A CA MechanicalInstructions
Circuit Diagrams and PWB Layouts SK4.0A CA 3. 5
Circuit Diagrams
Circuit Diagrams and PWB Layouts SK4.0A CA 3. 6
Layout Mono Carrier (Top Side)
Circuit Diagrams and PWB Layouts SK4.0A CA 3. 7
Layout Mono Carrier (Bottom Side)
Circuit Diagrams and PWB Layouts SK4.0A CA 3. 8
ULTRA-SLIM Top Layer
ULTRA-SLIM Bottom Layer
Circuit Diagrams and PWB Layouts SK4.0A CA 3. 9
Side AV Top Layer
Side AV Bottom Layer
Circuit Diagrams and PWB Layouts SK4.0A CA 3. 10
Layout Front Control Panel (Top Side)
Layout Front Control Panel (Bottom Side)
H001
RD3 RD2 RD5 RD4 M001
CR1 LED
RR1 J003
EN 11 4. SK4.0A CA ICData Sheet
ICData Sheet EN 12 4. SK4.0A CA
EN 13 4. SK4.0A CA ICData Sheet
ICData Sheet EN 14 4. SK4.0A CA
EN 15 4. SK4.0A CA ICData Sheet
V P1 1 V P1 1
V FB 2 V P3 2
V P2 3 V P2 3
GND 4 TDA4865J GND 4 TDA4865AJ
VOUT 5 VOUT 5
INN 6 INN 6
INP 7 INP 7
001aad298 001aad299
Fig 3. Pin con uration for DBS7P Fig 4. Pin con uration for DBS7P
(TDA4865J) (TDA4865AJ)
Pin description
Symbol Pin Description
TDA4865J TDA4865AJ
V P1 1 1 positive supply voltage 1
V FB 2 - Flyback supply voltage
V P3 - 2 Flyback generator output
V P2 3 3 supply voltage 2 for vertical output
GND 4 4 ground or negative supply voltage
VOUT 5 5 vertical output
INN 6 6 inverted input of differential input stage
INP 7 7 non-inverted input of differential input stage
ICData Sheet EN 16 4. SK4.0A CA
Ic601:
