Image preview - the first page of the document



>> Download g110.repair tips documenatation <<

Text preview - extract from the document

Philips G110




                             TV Repair Database




                             Philips                                                                                              Check C2366 (100 nF; 4822 122 33496).
                                             G110            At times no picture.
                             Philips                                                                                              Check capacitor C2366 (100 nF; 4822 122 33496).
                                             G110            At times no synchronization.
                             Philips                                                                                              Check and replace C 2509 (4822 124 40244)
                                             G110            Bottom fold over
                             Philips
                                             G110            Brightness too high/fly-back line visible                            Check/replace IC 7465 (TEA 5101A/P; 4822 209 73832) Check/replace R3375 (180 Ohm;              4822 111 30542)
                             Philips                                                                            CHECK - D6612 , 6614 ( CHECK DRIVE WAVEFORM TO BUT11 , SWITCH ON DELAY PROBABLY
                                             G110            BUT11AF S.C. AFTER P.SUPP KIT FITTED AND SET RUN I MISSING )
                             Philips                                                                                              Replace U 1003 (4822 212 23371) non TOP
                                             G110            Characters wrong                                                     Replace U 1003 (4822 212 23519)
                             Philips         G110            CHOPPER + LINE TRANSISTORS SC                                        C2546 8n2 2kv
                             Philips         G110            Chopper tr blows at sw on even after fitting kit                     OK if mains wound up slowly - check on/off sw & Positor in degaussing cct
                             Philips         G110            Chopper tr blows in st/by - ok when ON                               D6646, D6649, Tr7655, Tr7656 & Tr7654 cleared the problem
                             Philips                                                                                              Fit mod - 2 x BYD73B diodes in series between b - e of BUT18AF (anode to base). Make sure Tr7654 is BC817
                                             G110            Chopper Tr BUT18AF fails periodically                                not BC845
                             Philips                                                                                              Remove: R3433 and R3430. Modify: R3431 into 100 kohm (4822 051 10404). Add: R3428 - 180 ohm (4822 051
                                             G110            Colour drifts to the right using the S-VHS input.                    10181) between C2432/R3433 and 12 IC7425.
                             Philips                                                                                              It is possible that on the G110 chassis a coloured flash may be seen when syncs are interrupted. For example
                                                                                                                                  when changing channels or on VCR playback in "still" or "search" modes. In the case of home video recordings,
                                             G110            Coloured flash on channel change and VCR features                    the edit points may be marked by a
                             Philips                                                                                              Service solution: Mount a resistor of 220k ohms in parallel with capacitor 2349 and replace resistors 3891, 3892
                                                                                                                                  and 3922 by 1k2 ohm types.
                                             G110            Coloured spots in picture (local dooming).                           Modification introduced in products. Sets with production number QG05/AG04.
