Image preview - the first page of the document
>> Download 21pt8867_94_dfu_eng documenatation <<
Text preview - extract from the document
Ultra SlimLine Television 21PT8867/94
21PT5547/94
Real Flat Television 21PT5437/94
Description: USER MANUAL(3P61)
Job No. Brand Name: PHILIPS
Model: P/No.
REV.: Scale:
Engineering Dept:
Artwork By: Date: 2007-06-04
Checked By: Date:
Approved By: Date:
9
Channel Edit 17
Channel Swap 18
Timer
General
Two people are required to lift and carry a TV that weighs more than 25 kg. Improper handling
of the TV can cause serious injury.
The surface on which the TV is placed has to be level and able to withstand its weight.
Air must be able to circulate freely through the ventilation slots. Do not place the TV in a
confined place.
Do not place naked flame sources such as lighted candles close to theTV.
Do not place a vase filled with water near the TV. Spills can results in electric shock. If water
gets into the TV, disconnect the TV from the mains and have it checked by a qualified technician.
Do not expose the TV or the batteries of the remote control to heat, direct sunlight, rain or
water.
During a thunder storm, do not touch any part of the TV, power cord or antenna cable.
Do not leave theTV in standby mode for an extended period of time. Instead disconnect it
from the mains.
Do not connect too much equipment to the same mains socket because it can result in fire or
electric shock.
Caring and cleaning of the TV
Disconnect the TV from the mains before you clean the TV. Use only a dry cloth.
Do not touch, push, rub or strike the screen with anything hard as this may scratch or damage
the screen permanently.
3
Check life span of batteries of the remote control.
4
5
For best playback performance:
Connect the audio cables from the DVD player to the AV IN sockets on the rear of the
TV.
Switch to the CVI mode on the TV by pressing the AV button on the remote.
*EXTL WOOFER is only available on 21PT5547/94
6
AV sockets on
the side of TV
VCR to DVD
VCR or DVD
You can also view the playback of VCR tapes or DVD
rear and side
rear and side
Switch to the AV mode by pressing the AV button on the remote.
*EXTL WOOFER is only available on 21PT5547/94
7
TUNER
Connect the video and audio RCA cables from the OUTPUT sockets of the VCR
to the AV in on the rear of the TV
*EXTL WOOFER out is only available on 21PT5547/94
8
WOOX
9
You can enter the main menu by pressing and holding the Volume - button first
before pressing theVolume + button
10
MAIN
PICTURE BRIGHTNESS
SOUND COLOUR
FEATURES CONTRAST
INSTALL SHARPNESS
COLOUR TEMP
CONTRAST +
MAIN
INSTALL
PICTURE LANGUAGE
SOUND AUTO STORE
FEATURES MANUAL STORE
INSTALL CH SWAP
INSTALL
INSTALL
LANGUAGE ENGLISH
AUTO STORE
MANUAL STORE
CH SWAP
NOTE:
11
MAIN
PICTURE BRIGHTNESS
SOUND COLOUR
FEATURES CONTRAST
INSTALL SHARPNESS
COLOUR TEMP
CONTRAST +
MAIN
INSTALL PICTURE LANGUAGE
SOUND AUTO STORE
FEATURES MANUAL STORE
INSTALL CH SWAP
INSTALL INSTALL
LANGUAGE ENGLISH
AUTO STORE
MANUAL STORE
CH SWAP
INSTALL
AUTO STORE LANGUAGE
AUTO STORE
MANUAL STORE
CH SWAP
AUTO STORE 139MHz
VHF-L
MAIN
PICTURE BRIGHTNESS
SOUND COLOUR
FEATURES CONTRAST
INSTALL SHARPNESS
COLOUR TEMP
CONTRAST +
NOTE:
12
MAIN
PICTURE BRIGHTNESS
SOUND COLOUR
FEATURES CONTRAST
INSTALL SHARPNESS
COLOUR TEMP
CONTRAST +
MAIN
INSTALL PICTURE LANGUAGE
SOUND AUTO STORE
FEATURES MANUAL STORE
INSTALL CH SWAP
INSTALL
INSTALL
LANGUAGE ENGLISH
AUTO STORE
MANUAL STORE
CH SWAP
INSTALL
LANGUAGE COLOUR SYS
MANUAL STORE
AUTO STORE SOUND SYS
MANUAL STORE BAND
CH SWAP SEARCH
CHANNEL
MORE.....
MANUAL STORE
MANUAL STORE COLOUR SYS
SOUND SYS
BAND
SEARCH
CHANNEL CHANNEL 2
FINE TUNE
NOTE:
13
MANUAL STORE
SEARCH COLOUR SYS
SOUND SYS
BAND
SEARCH 39
CHANNEL
FINE TUNE
MANUAL STORE
COLOUR SYS
SOUND SYS
You can also enter frequency BAND
of the channel using digital SEARCH 78
keys directly. CHANNEL
FINE TUNE
MANUAL STORE
COLOUR SYS
SOUND SYS
6 9 BAND
SEARCH 128
CHANNEL
FINE TUNE
NOTE:
14
COLOUR SOUND AUTO
NOTE
MANUAL STORE
COLOUR SYS AUTO
SOUND SYS
BAND
SEARCH
CHANNEL
FINE TUNE
AUTO
MANUAL STORE
COLOUR SYS PAL
SOUND SYS
BAND
SEARCH
CHANNEL
FINE TUNE
SOUND SYS
MANUAL STORE
COLOUR SYS
SOUND SYS AUTO
BAND
SEARCH
CHANNEL
AUTO FINE TUNE
MANUAL STORE
COLOUR SYS
SOUND SYS BG
BAND
SEARCH
CHANNEL
FINE TUNE
NOTE:
15
MAIN
PICTURE BRIGHTNESS
SOUND COLOUR
FEATURES CONTRAST
INSTALL SHARPNESS
COLOUR TEMP
CONTRAST +
INSTALL
MAIN
PICTURE LANGUAGE
SOUND AUTO STORE
FEATURES MANUAL STORE
INSTALL CH SWAP
INSTALL
MANUAL STORE
INSTALL
LANGUAGE COLOUR SYS
AUTO STORE SOUND SYS
MANUAL STORE MANUAL STORE BAND
CH SWAP SEARCH
CHANNEL
MORE.....
FINE TUNE
MANUAL STORE
SOUND SYS
BAND
SEARCH
CHANNEL
FINE TUNE
SKIP
NOTE:
16
MAIN
PICTURE LANGUAGE
SOUND AUTO STORE
FEATURES MANUAL STORE
INSTALL CH SWAP
INSTALL
INSTALL
LANGUAGE COLOUR SYS
AUTO STORE SOUND SYS
MANUAL STORE
MANUAL STORE BAND
CH SWAP SEARCH
CHANNEL
MORE.....
MANUAL
STORE
SKIP MANUAL STORE
SOUND SYS
BAND
SEARCH
CHANNEL
ON FINE TUNE
SKIP OFF
To edit other channels,
please press button to
MANUAL STORE
select CHANNEL MENU.
SOUND SYS
Key in the channel number BAND
SEARCH
to be select then repeat 6 CHANNEL 2
to 7. FINE TUNE
SKIP
NOTE:
17
CHANNEL SWAP
CH SWAP allows you to exchange the programs of two channels.
MAIN
PICTURE BRIGHTNESS
SOUND COLOUR
FEATURES CONTRAST
INSTALL SHARPNESS
COLOUR TEMP
CONTRAST +
MAIN
INSTALL PICTURE LANGUAGE
SOUND AUTO STORE
FEATURES MANUAL STORE
INSTALL CH SWAP
INSTALL
INSTALL
LANGUAGE ENGLISH
AUTO STORE
MANUAL STORE
CH SWAP
INSTALL
LANGUAGE FROM
CH SWAP
AUTO STORE TO
MANUAL STORE EXCHANGE
CH SWAP
CH SWAP
CH SWAP FROM 1
TO
EXCHANGE
NOTE:
18
CHANNEL SWAP
Press button to select CH SWAP
two channels that you FROM
want to exchange their TO 3
EXCHANGE
programs, such as from
1to 3.
CH SWAP
EXCHANGE FROM
TO
EXCHANGE SWAP ?
Press button to exchange CH SWAP
the programs of two FROM
channels. TO
EXCHANGE SWAPPED
NOTE:
19
MAIN
PICTURE BRIGHTNESS
SOUND COLOUR
FEATURES CONTRAST
INSTALL SHARPNESS
COLOUR TEMP
CONTRAST +
PICTURE PICTURE
BRIGHTNESS 50
COLOUR
CONTRAST
SHARPNESS
COLOUR TEMP
CONTRAST+
BRIGHTNESS
COLOUR 50
CONTRAST
SHARPNESS
COLOUR TEMP
CONTRAST+
NOTE:
BRIGHTNESS
COLOUR
CONTRAST
SHARPNESS
COLOUR TEMP
CONTRAST+ Select ON to optimise the total contrast for improved
picture quality.
20
TIMER
MAIN
PICTURE TIMER
SOUND NR
FEATURES
FEATURES INSTALL
FEATURES
FEATURES
TIMER CLOCK
NR ON TIME
ON CHANNEL
OFF TIME
SLEEP TIME
CH SWITCH
TIMER
CLOCK
ON TIME -- --
ON CHANNEL
OFF TIME
SLEEP TIME
CH SWITCH
6
TIMER menu items Activities
CLOCK Auto clock when setting working status or standby status.
ON TIME Setting time to awake theTV from standby status.
ON CHANNEL Setting channel which will be on when theTV is a woken.
OFF TIME Setting time to standby the TV from work status.
SLEEP TIME Setting time when the TV turn to sleep status from now.
CH SWITCH Setting time when the TV switch to another channel.
SWITCH TO Setting time when switch to pointed channel.
NOTE: All the timer settings will be reset when the main are switched off.
21
NOTE: Applicable for TV model 21PT5547 only.
MAIN
PICTURE BRIGHTNESS
SOUND COLOUR
FEATURES CONTRAST
INSTALL SHARPNESS
COLOUR TEMP
CONTRAST +
SOUND
MAIN
PICTURE TREBLE
SOUND BASS
FEATURES BALANCE
INSTALL SURROUND
SOUND
SOUND
TREBLE 50
BASS
BALANCE
SURROUND
NOTE:
SOUND menu items
TREBLE TREBLE
BASS BASS
BALANCE BALANCE
SURROUND Select the effect: MONO or SPATIAL in mono sound
channel .
Select the effect: INCR.SURROUND or STEREO in
stereo sound channel.
22
4
PERSONAL, SOFT NATURAL, RICH
,
PERSONAL
PERSONAL
SOFT
SOFT
NATURAL
NATURAL
RICH
RICH
23
NOTE: Applicable for TV model 21PT5547 only.
5
PERSONAL, VOICE, THEATRE, MUSIC ,WOOX
PERSONAL PERSONAL
VOICE
VOICE
THEATRE
MUSIC THEATRE
WOOX :Super bass speaker(WOOX) is
set to on, emphasize super bass tone.
MUSIC
WOOX
NOTE:
24
21PT8867/94 21PT5437/94 21PT5547/94
Ultra Slim Picture Tube Real Flat
54cm
51cm
Contrast +
21PT8867/94: 300W PMPO 21PT5547/94: 500W PMPO 21PT5437/94:300W PMPO
PAL /BG / DK/ I
Video Playback PAL, NTSC
CVI, CVBS In,Monitor Out;Antenna In (75 )
Subwoofer out (for 21PT5547/94 only)
CVBS In
100-240V ,50/60 Hz
72W 72W
22.64Kg
20.14Kg
23Kg 27Kg
594x461x327mm 594x461x489mm
25
