Image preview - the first page of the document
>> Download TC71UCA_ET-SB-SI_1289202929 documenatation <<
Text preview - extract from the document
Color Television Chassis
TC7.1U
CA
H_17090_000.eps
150307
Contents Page
1. Technical Specifications, Connections, and Chassis
Overview 2
2. Safety Instructions, Warnings, and Notes 4
3. Directions for Use 5
4. Mechanical Instructions 6
5. Service Modes, Error Codes, and Fault Finding 9
6. Block Diagrams, Test Point Overview, and
Waveforms
Block Diagram Mono Carrier 13
Block Diagram ATSC Module 14
7. Circuit Diagrams and PWB Layouts
Mono Carrier (A) 15 16-17
CRT Panel (B) 18 16-17
ATSC: Power Reset (C1) 19 26-27
ATSC: Tuner Link (C2) 20 26-27
ATSC: Audio Video (C3) 21 26-27
ATSC: Embedded (C4) 22 26-27
ATSC: DDR Memory (C5) 23 26-27
ATSC: Flash Memory (C6) 24 26-27
ATSC: Power GND (C7) 25 26-27
Side AV & Control Panel (D) 28 28
Front Control Panel (E) 29 29
8. Alignments 31
9. Circuit Descriptions, Abbreviation List, and IC Data
Sheets 35
Abbreviation List 38
10. Spare Parts List 39
11. Revision List 42
