Image preview - the first page of the document



>> Download DVDR3510V05_SB-ET-EX-SI_4777686896 documenatation <<

Text preview - extract from the document

                                                                                                                                                    DVD Recorder / VCR                                           DVDR3510V


          3               Enjoy
        Start playback
        A From a disc
        A Press DVD on the remote control.
                                                                               Start recording
                                                                               A Record to DVD or VCR
                                                                               A Press DVD to record to a recordable DVD.
                                                                                                                                                    Quick Start Guide
        B Press OPEN/CLOSE Z, load a disc and close the disc                      OR, press VCR to record to a VHS tape.
             tray.                                                             B Load in a blank recordable DVD to the disc tray or a
        C Press PLAY/PAUSE u to start playback.                                   VHS tape to the tape deck.
        D To stop playback, press STOP x.                                      C Press SOURCE repeatedly to select the source to
                                                                                  record from (eg, TUNER, CAM1, DV, EXT1 or EXT2).
                                                                                  To record a TV programme, use P+/- on the
        B       From a VHS tape                                                   remote control to select a programme channel.
                                                                               D Press REC MODE repeatedly to select a desired
        A Press VCR on the remote control.
                                                                                  recording mode (refer to the Record Mode table).
        B Insert a pre-record VHS tape into the tape deck.
                                                                               E Press REC z to start recording.
             Press REW m to rewind the tape if necessary to the
             beginning of the recording.
        C Press PLAY/PAUSE u to start playback.
        D To stop playback, press STOP x.
                                                                                    Note To set the recording time, press REC z
                                                                                    repeatedly to extend the recording time in 30 minute
                                                                                    increments. The recording will stop automatically at
                                                                                    the designated end time.
                                                                                                                                                                                              1      Connect
                                                                                  To record from an external device, press PLAY
                                                                                  on the device to start playback.
                                                                                                                                                                                              2      Set up
                                                                               F To stop the recording, press STOP x.
                                                                                                                                                                                              3       Enjoy
                                                                               B    Dubbing (VCR
