Image preview - the first page of the document
>> Download vr685_07_dfu_eng documenatation <<
Text preview - extract from the document
&
OPERATING INSTRUCTIONS IN BRIEF
The remote control Front of the video recorder
EJECT J Eject STANDBY m Standby
STANDBY m Standby AUDIO L Audio input, left channel
CHILD LOCK u Child lock AUDIO R Audio input, right channel
SYSTEM Special function VIDEO Video input socket
SP/LP SP/LP selection RECORD n Record
MONITOR TV monitor function PROGRAMME r Down/number minus
0-9 Digit buttons 0-9 PROGRAMME q Up/number plus
SELECT Function selector AUTOINSTALL Installation button
CLEAR (CL) Reset, clear STOP/EJECT ? Stop/Cassette eject
TIMER k 'VIDEOPlus' / 'TIMER' programming H Rewind/Reverse scanning
OK Confirm button PLAY G Playback
P q Up/number plus I Forward wind/ Forward scanning
D Menu left
C Menu right
P r Down/number minus
PLAY G Playback
H Rewind/Reverse scanning
STOP h Pause/Stop, Tuner-mode
I Forward wind/ Forward scanning
INDEX E Index search
RECORD/OTR n Record
STILL R Still picture
Additional TV functions:
Sq TV volume +
Sr TV volume -
TV y TV sound off
TV m Switch off TV
TV q Programme number +
TV r Programme number -
&
Programming with 'VIDEOPlus+' How to programme a recording manually
All the information required for a programming is encoded in the VIDEOPlus+ code. 1 Switch on the TV set. Press the TIMER k button twice.
1 Switch on the TV set. 2 Select a free TIMER block, using the P q or the P r button. Press the TIMER k button.
2 Press the TIMER k button on the remote control. DATE PROG START V/P END
01 01 20:00 21:30
3 With the digit buttons 0-9 , enter the VIDEOPlus+ code (up to 9 digits) printed in your TV guide next to the
start time of a TV programme.
If you make a mistake, clear with the CLEAR (CL) button.
4 If you want to programme at daily or weekly intervals, press the SELECT button until 'D-DAILY' (daily inter-
------------------------
vals) or 'W-WEEKLY' (weekly intervals) appears in the display. The 'daily intervals' function can only be used NEXT gTIMER CLEAR gCL
for recordings to be made from Mondays to Fridays inclusive. -/+ 0-9 D/WgSELECT OK
5 Confirm the entries with the OK button . The resultant data appears on the TV screen.
3 With the TIMER k the C or the D button you can select between the entries 'DATE' (date), 'PROG'
(programme number), 'START' (start time) and 'END' (end time).
Note: If you use VIDEOPlus+ for the first time for this TV channel, the line 'SELECT PROG' appears when you
You can enter or adjust data, using the P q or the P r button or the digit buttons 0-9 . Confirm each
confirm the VIDEOPlus+ code. Instead of 'E2', select the programme number for this particular TV channel,
entry with the TIMER k button.
using the digit buttons 0-9 and confirm with the OK button.
You can switch 'VPS/PDC' ('V/P') on and off at step 'START' with the SELECT button.
* Switch 'VPS' or 'PDC' (V/P) on or off with the SELECT button.
You can select between 'D' (daily intervals) or 'W' (weekly intervals) at step 'DATE' with the SELECT but-
* If you wish to set a later end time for a recording, press the P q button at step 5 . Each time you press
ton.
the P q button you will add 15 minutes to the end time.
* If e.g.: '20:00' flashes in the display, please set the clock. 4 Finally, press the OK button. Programming is now complete.
6 Finally, press the OK button. Programming is now complete. 5 Make sure that a cassette without erase protection has been loaded. Switch to standby with the
The data has been stored in a TIMER block. STANDBY m button.
A programmed recording will only function when the video recorder is switched to standby with the
7 Make sure that a cassette without erase protection has been loaded. Switch to standby with the STANDBY m button.
STANDBY m button.
A programmed recording will only function when the video recorder is switched to standby with the Note:
STANDBY m button. * Clear a TIMER-block: After step 1 , select the TIMER block you want to clear with the P q or the
P r button. Press the CLEAR (CL) button.
* If e.g.: '20:00' flashes in the display, the clock must be set.
OPERATING INSTRUCTIONS PHILIPS VR685
Congratulations on the purchase of one of the most sophisti- Contents INSTALLATION 2 2 00 1 Connecting
Page 1
cated and simple-to-use video recorders (VCR) on the market.
With this VCR you can record and play VHS-standard VCR with scart cable 2 2 00 1 Connecting
cassettes. VCR without scart cable 2 3 00 1 Adjusting
the modulator frequency 2 3 00 1 Automatic
adjustment of modulator frequency 2 3 00 1
Important notes for operation 2 3 00 1 Saving
energy 2 4 00 1 Connecting additional
Please take the time to read this operating manual before equipment 2 4 00 1 User guide 2 4 00 1
using your video recorder.
Autoinstall 2 5 00 1 Setting the clock 2 5 00 1
FOLLOW TV 2 6 00 1 Manual Channel
Safety instructions and other notes Number Allocation 2 6 00 1 Monitor function
