                                                                                                                             ORDER NO.
                                                                                                                            RRV2173

700 DISC CHANGER


DRM-7000
50 DISC MAGAZINE                                                      50 DISC MAGAZINE LOCK TYPE

DRM-AF751,DRM-AL751
20 DISC HYPER MAGAZINE

DRM-AH721
POWER SUPPLAY UNIT

DRM-PW701
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                                                 Model
    Type                                                                                 Power Requirement                     Remarks
             DRM-7000 DRM-AF751 DRM-AL751 DRM-AH721 DRM-PW701
TUCYV/WL           O             -              -               -         O        AC100 - 240V
   WL              -             O              O               O         -
