Image preview - the first page of the document

>> Download pioneer_avh-5400dvd_avh-5450dvd_crt4782 documenatation <<

Text preview - extract from the document

ORDER NO.
CRT4782
AVH-5400DVD/XNUW5

DVD RDS AV RECEIVER

AVH-5400DVD /XNUW5
AVH-5400DVD/XNUC
AVH-5450DVD/XNRD
AVH-5450DVD/XNRI
This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks

CX-3268 CRT4534 MS7 DVD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly

PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2011
K-ZZZ SEPT. 2011 Printed in Japan
1 2 3 4

SAFETY INFORMATION

A CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.

WARNING

B This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive
harm.
Health & Safety Code Section 25249.6 - Proposition 65

Where in a manufacturer's service documentation, for example in circuit diagrams or lists
of components, a symbol is used to indicate that a specific component shall be replaced only
by the component specified in that documentation for safety reasons, the following symbol shall
be used:

- Safety Precautions for those who Service this Unit.
C
When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.

Caution:
1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.

CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

D
CAUTION
This product is a class 1 laser product classi-
fied under the Safety of laser products, IEC
60825-1:2007, and contains a class 1M laser
module. To ensure continued safety, do not re-
move any covers or attempt to gain access to
the inside of the product. Refer all servicing to
qualified personnel.

E
CAUTION--CLASS 1M INVISIBLE LASER
RADIATION WHEN OPEN, DO NOT VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.

WARNING!
The AEL (accessible emission level )of the laser power output is less than CLASS 1
but the laser component is capable of emitting radiation exceeding the limit for
CLASS 1.
A specially instructed person should do servicing operation of the apparatus.
F

AVH-5400DVD/XNUW5
2
1 2 3 4
5 6 7 8

Laser diode characteristics
Wave length:
DVD:660 nm to 670 nm
CD:780 nm to 800 nm
Focus lens on Maximum output:
CD:6.26 mW(Emitting period :9 sec.)
DVD:1.27 mW (Emitting period : unlimited)

Additional Laser Caution B

Transistors Q1103 and Q1104 in PCB drive the laser diodes for DVD and CD
respectively. When Q1103 or Q1104 is shorted between their terminals,
the laser diodes for DVD or CD will radiate beam. If the top cover is removed
with no disc loaded while such short-circuit is continued, the naked eyes may
be exposed to the laser beam.

CAUTION C
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacture.
Discord used batteries according to the manufacture's instructions.

AVH-5400DVD/XNUW5
5 6 7 8
3
1 2 3 4

CONTENTS
SAFETY INFORMATION..................................................................................................................................... 2
1. SERVICE PRECAUTIONS ............................................................................................................................... 5
1.1 SERVICE PRECAUTIONS ........................................................................................................................ 5
A
1.2 NOTES ON SOLDERING .......................................................................................................................... 6
2. SPECIFICATIONS ............................................................................................................................................ 7
2.1 SPECIFICATIONS ..................................................................................................................................... 7
2.2 DISC/CONTENT FORMAT ...................................................................................................................... 10
3. BASIC ITEMS FOR SERVICE........................................................................................................................ 10
3.1 CHECK POINTS AFTER SERVICING..................................................................................................... 10
3.2 PCB LOCATIONS .....................................................................................................................................11
3.3 JIGS LIST ................................................................................................................................................ 12
3.4 CLEANING............................................................................................................................................... 13
4. BLOCK DIAGRAM.......................................................................................................................................... 14
4.1 OVERALL CONNECTION DIAGRAM...................................................................................................... 14
4.2 BLOCK DIAGRAM ................................................................................................................................... 16
B
5. DIAGNOSIS.................................................................................................................................................... 26
5.1 OPERATIONAL FLOWCHART ................................................................................................................ 26
5.2 INSPECTION METHOD OF PICKUP UNIT............................................................................................. 27
5.3 DIAGNOSIS FLOWCHART ..................................................................................................................... 30
5.4 ERROR CODE LIST ................................................................................................................................ 48
5.5 CONNECTOR FUNCTION DESCRIPTION ............................................................................................. 50
5.6 MECHANICAL DESCRIPTION ................................................................................................................ 51
6. SERVICE MODE ............................................................................................................................................ 55
6.1 DVD TEST MODE ................................................................................................................................... 55
6.2 MONITOR TEST MODE .......................................................................................................................... 66
7. DISASSEMBLY .............................................................................................................................................. 76
8. EACH SETTING AND ADJUSTMENT ........................................................................................................... 89
C 8.1 DVD ADJUSTMENT ................................................................................................................................ 89
8.2 MOTHER PCB ADJUSTMENT ................................................................................................................ 94
8.3 MONITOR PCB ADJUSTMENT............................................................................................................... 96
9. EXPLODED VIEWS AND PARTS LIST.......................................................................................................... 98
9.1 PACKING ................................................................................................................................................. 98
9.2 EXTERIOR (1) ....................................................................................................................................... 100
9.3 EXTERIOR (2) ....................................................................................................................................... 102
9.4 EXTERIOR (3) ....................................................................................................................................... 104
9.5 EXTERIOR (4) ....................................................................................................................................... 106
9.6 DVD MECHANISM MODULE .................................................................................................................110
10. SCHEMATIC DIAGRAM..............................................................................................................................112
10.1 MOTHER PCB (ANALOG PART) .........................................................................................................112
D 10.2 MOTHER PCB (SYSTEM PART)(GUIDE PAGE) .................................................................................114
10.3 MOTHER PCB (POWER SUPPLY PART) ........................................................................................... 120
10.4 MOTHER PCB (MMD PART)(GUIDE PAGE) ...................................................................................... 122
10.5 MOTHER PCB (I/F PART)(GUIDE PAGE)........................................................................................... 128
10.6 TUNER PCB ........................................................................................................................................ 134
10.7 DVD CORE UNIT (MS7)(GUIDE PAGE) ............................................................................................. 136
10.8 COMPOUND UNIT(A) and COMPOUND UNIT(B) .............................................................................. 142
10.9 PANEL PCB ......................................................................................................................................... 144
10.10 KEYBOARD PCB............................................................................................................................... 146
10.11 MAIN PCB UNIT, SWITCH PCB UNIT and VOLUME PCB UNIT ...................................................... 148
10.12 MONITOR PCB (MONITOR PART)(GUIDE PAGE)........................................................................... 150
10.13 MONITOR PCB (BACKLIGHT PART)................................................................................................ 156
E 10.14 WAVEFORMS .................................................................................................................................... 158
11. PCB CONNECTION DIAGRAM.................................................................................................................. 160
11.1 MOTHER PCB ..................................................................................................................................... 160
11.2 TUNER PCB......................................................................................................................................... 164
11.3 DVD CORE UNIT(MS7) ....................................................................................................................... 166
11.4 COMPOUND UNIT(A) and COMPOUND UNIT(B) .............................................................................. 170
11.5 PANEL PCB ......................................................................................................................................... 171
11.6 KEYBOARD PCB ................................................................................................................................. 172
11.7 MAIN PCB UNIT, SWITCH PCB UNIT and VOLUME PCB UNIT ........................................................ 173
11.8 MONITOR PCB .................................................................................................................................... 174
12. ELECTRICAL PARTS LIST ........................................................................................................................ 178

AVH-5400DVD/XNUW5
4
1 2 3 4
5 6 7 8

1. SERVICE PRECAUTIONS
1.1 SERVICE PRECAUTIONS
A

1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations),
and should keep the safety during servicing by following the safety instructions described in this manual.
2. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic
induction.
3. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during
power-on mode may damage the ICs inside the unit.
4. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment
(shorting-solder) by referring to "the DISASSEMBLY" .
5. After replacing the pickup unit, be sure to skew adjustment.
6. When a flash ROM needs to be replaced by service, do not replace an IC but a core unit (as no encryption key is B
written in a flash alone).
7. During disassembly, be sure to turn the power off since an internal IC might be destroyed when a connector
is plugged or unplugged.
8. Countermeasures to user complaints on iPhone/iPod touch lip synchronization
When a video is replayed, the video and audio may be out of synchronization depending on the connected
iPod or iPhone.
If it is annoying, perform the following operation.
However, this operation will slightly deteriorate the sound quality of the iPod source.
Also, it will disable the ASR function when the iPod source is used.

[Default]
C
Audio digital mode

[Switching procedure]
Press MODE and EJECT and turn on Accessory simultaneously

The above switches the "Audio digital mode" to the "Audio analog mode".
When the mode is switching, the BEEP1 sound will be heard.

[Supplement]
