Image preview - the first page of the document
>> Download pioneer_avh-3500dvd_avh-3550dvd documenatation <<
Text preview - extract from the document
ORDER NO.
CRT5348
AVH-3500DVD/XEUC
DVD AV RECEIVER
AVH-3500DVD /XEUC
AVH-3550DVD /XERD
AVH-3550DVD /XERC
AVH-3550DVD /XERI
AVH-3500DVD /XEUW5
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2013
K-ZZZ JULY 2013 Printed in Japan
1 2 3 4
SAFETY INFORMATION
CAUTION
A
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
WARNING
This product may contain a chemical known to the State of California to cause cancer, or birth defects or
other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
B
Where in a manufacturer's service documentation, for example in circuit diagrams or lists
of components, a symbol is used to indicate that a specific component shall be replaced only
by the component specified in that documentation for safety reasons, the following symbol shall
be used:
- Safety Precautions for those who Service this Unit.
When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.
Caution:
C 1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
CAUTION
This product is a class 1 laser product
classified under the Safety of laser products,
IEC 60825-1:2007.
D CAUTION
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacture.
Discord used batteries according to the manufacture's instructions.
E
F
AVH-3500DVD/XEUC
2
1 2 3 4
5 6 7 8
CONTENTS
SAFETY INFORMATION .....................................................................................................................................2
1. SERVICE PRECAUTIONS................................................................................................................................4
1.1 SERVICE PRECAUTIONS .........................................................................................................................4 A
1.2 NOTES ON SOLDERING...........................................................................................................................4
2. SPECIFICATIONS.............................................................................................................................................5
2.1 SPECIFICATIONS ......................................................................................................................................5
2.2 DISC/CONTENT FORMAT.......................................................................................................................10
3. BASIC ITEMS FOR SERVICE ........................................................................................................................ 11
3.1 CHECK POINTS AFTER SERVICING ..................................................................................................... 11
3.2 PCB LOCATIONS.....................................................................................................................................12
3.3 JIGS LIST .................................................................................................................................................13
3.4 CLEANING ...............................................................................................................................................13
4. BLOCK DIAGRAM ..........................................................................................................................................14
4.1 OVERALL CONNECTION DIAGRAM ......................................................................................................14
4.2 BLOCK DIAGRAM....................................................................................................................................16 B
5. DIAGNOSIS ....................................................................................................................................................18
5.1 OPERATIONAL FLOWCHART.................................................................................................................18
5.2 ERROR CODE LIST.................................................................................................................................19
5.3 CONNECTOR FUNCTION DESCRIPTION .............................................................................................20
6. SERVICE MODE.............................................................................................................................................21
6.1 SOFTWARE VERSION UP METHOD......................................................................................................21
6.2 SOFTWARE VERSION INFORMATION DISPLAY ..................................................................................21
7. DISASSEMBLY ...............................................................................................................................................22
8. EACH SETTING AND ADJUSTMENT............................................................................................................27
8.1 TOUCH PANEL ADJUSTMENT ...............................................................................................................27
9. EXPLODED VIEWS AND PARTS LIST ..........................................................................................................28
C
9.1 PACKING..................................................................................................................................................28
9.2 EXTERIOR (1) ..........................................................................................................................................30
9.3 EXTERIOR (2) ..........................................................................................................................................32
9.4 EXTERIOR (3) ..........................................................................................................................................34
9.5 EXTERIOR (4) ..........................................................................................................................................36
10. SCHEMATIC DIAGRAM................................................................................................................................40
10.1 MB PCB ASSY (TUNER/RDS PART).....................................................................................................40
10.2 MB PCB ASSY (MPEG PART) ...............................................................................................................42
10.3 MB PCB ASSY (MOTOR PART) ............................................................................................................44
10.4 MB PCB ASSY (AUDIO_VIDEO PART) .................................................................................................46
10.5 MB PCB ASSY (POWER AMP PART) ...................................................................................................48
10.6 MB PCB ASSY (MCU PART) .................................................................................................................50 D
10.7 MB PCB ASSY (POWER PART) ............................................................................................................52
10.8 MB PCB ASSY (INTERFACE PART) .....................................................................................................54
10.9 KB PCB and AUX PCB...........................................................................................................................56
10.10 TFT SMT UNIT (1/2).............................................................................................................................58
10.11 TFT SMT UNIT (2/2) .............................................................................................................................60
10.12 MAIN PCB UNIT and SW PCB UNIT ...................................................................................................62
11. PCB CONNECTION DIAGRAM ....................................................................................................................64
11.1 MB PCB ASSY........................................................................................................................................64
11.2 KB PCB...................................................................................................................................................68
11.3 AUX PCB ................................................................................................................................................69
11.4 TFT SMT UNIT .......................................................................................................................................70
11.5 MAIN PCB UNIT .....................................................................................................................................74 E
11.6 SW PCB UNIT ........................................................................................................................................75
12. ELECTRICAL PARTS LIST...........................................................................................................................76
F
AVH-3500DVD/XEUC
5 6 7 8
3
1 2 3 4
1. SERVICE PRECAUTIONS
1.1 SERVICE PRECAUTIONS
A
1. You should conform to the regulations govering the product (safety, radio and noise, and other regulations),
and should keep the safety during servicing by following the safety instructions described in this manual.
2. Be careful about an internal sharp edge.
3. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by
electrostatic induction.
4. Be careful in handing made from metal parts. There might be burr at the edge of it.
5. Two kinds of resetting are available
Press [RESET] with a pen tip or other pointed
1) Press RESET Button at the lower left of Front Panel. instrument.
Without entire initialization.
Microcomputer restarting (emergency resetting at function trouble) .
B 2) Perform [Default Setting] initialization in System Menu
Perform product initialization except a part of items.
RESET
Please carry it out when updating software.
6. Any component parts in the DVD Mechanism Module of this model can not be supplied.
If you need to replace any parts in the DVD Mechanism Module, replace whole of DVD Mechanism Module.
7. The sheet (121490000888) fixing a flexible cable onto the DVD mechanism is not reusable.
If you removed this sheet, replace it with the new one.
8. Disc Removal Method At No Power
You can add a about 3V-4V DC voltage between "Load+"(Red) with "Load-"(White).
C
White : Load-
Red : Load+
D
1.2 NOTES ON SOLDERING
For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
E accompanied by reworking of soldering.
Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 C.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 C in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.
Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
temperatures (hard to melt/easy to harden).
The following lead-free solders are available as service parts:
Parts numbers of lead-free solder:
F
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.
AVH-3500DVD/XEUC
4
1 2 3 4
5 6 7 8
2. SPECIFICATIONS
2.1 SPECIFICATIONS
AVH-3500DVD/XEUC A
General
Rated power source ..........................................14.4 V DC (allowable voltage range: 10.5 V to 16 V
DC)
Preout maximum output level ............................2 V
Maximum current consumption .........................10.0 A
Backup current ..................................................5 mA or less
