Image preview - the first page of the document
>> Download pioneer_avic-f320bt_crt4541_parts documenatation <<
Text preview - extract from the document
ORDER NO.
CRT4541
GPS NAVIGATION AUDIO SYSTEM
AVIC-F320BT
AVIC-F320BT /XSAU
/XSEU5
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by Pioneer Corporation is under license.
Other trademarks and trade names are those of their respective owners.
This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model No. Order No. Mech. Module Remarks
AVIC-U310BT/XSUC CRT4377 (AVIC-F320BT/XSEU5,AVIC-F320BT/XSAU)
CX-3240 CRT4350 S10.5COMP2-iPod/USB CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2010 K-ZZZ. MAR. 2010 Printed in Japan
1 2 3 4
Change the jig number. (Page 32, 38, 46)
GGV1345 -> GGS1089
A
EXPLODED VIEWS AND PARTS LIST
PACKING(Page 60)
PACKING SECTION PARTS LIST *:Non spare part
Mark No. Description AVIC-F310BT/XSEU5 AVIC-F320BT/XSEU5
2 Unit Box CHG6921 CHG7218
3 Contain Box CHL6921 CHL7218
4 Protector CHP3830 CHP3997
B 5 Screw BMZ50P080FTC Not used
7 Cord Assy CDP1246 CDP1331
* 10 Polyethylene Bag CEG-127 Not used
12 Sub Unit Box CHG6918 CHG7355
13 Screw CMZ50P080FTC Not used
15 IM CD-ROM CPJ1286 CPJ1307
19 GPS Antenna Assy CXE2705 CXE3204
21 Sheet CZN7151 CZN8510
C
24-1 Quick Start Guide CRB3025 CRB3290
24-2 Quick Start Guide CRB3026 CRB3291
24-3 Quick Start Guide CRB3027 CRB3292
24-4 Quick Start Guide CRB3028 CRB3293
24-5 Quick Start Guide CRB3029 CRB3294
24-6 Quick Start Guide CRB3030 CRB3295
24-7 Important Information CRD4416 CRD4478
24-8 Installation Manual CRD4417 CRD4479
D
Mark No. Description AVIC-F310BT/XSAU AVIC-F320BT/XSAU
2 Unit Box CHG6920 CHG7219
3 Contain Box CHL6920 CHL7219
7 Cord Assy CDP1247 CDP1332
13 Screw CMZ50P080FTC Not used
15 IM CD-ROM CPJ1287 CPJ1308
19 GPS Antenna Assy CXE2705 CXE3204
E 21 Sheet CZN7151 CZN8510
23 Bag CMX1035 Not used
24-1 Quick Start Guide CRB3032 CRB3297
24-7 Important Information CRB3033 CRB3298
24-8 Installation Manual CRB3034 CRB3299
F
AVIC-F320BT/XSEU5
2
1 2 3 4
5 6 7 8
Owner's Manual,Installation Manual
Part No. Language Model
CRB3290 English EU5
A
CRB3291 Spanish
CRB3292 German
CRB3293 French
CRB3294 Italian
CRB3295 Dutch
CRD4478 English, Spanish, German, French, Italian, Dutch
CRD4479 English, Spanish, German, French, Italian, Dutch
CRB3297 English AU
CRB3298 English
CRB3299 English
B
CONTENTS OF CD-ROM (Operation Manual)
Part No. Language CD-ROM Part No.
* CRB3284 English CPJ1307
* CRB3285 Spanish
* CRB3286 German
* CRB3287 French
* CRB3288 Italian
* CRB3289 Dutch
* CRB3296 English CPJ1308
All operation manuals are supplied in PDF files by the CD-ROM. C
Regarding the availability of paper manual, contact Pioneer Service representative in your region.
D
E
F
AVIC-F320BT/XSEU5
5 6 7 8
3
1 2 3 4
EXTERIOR(1)(Page 64)
EXTERIOR(1) SECTION PARTS LIST *:Non spare part
Mark No. Description AVIC-F310BT/XSEU5 AVIC-F320BT/XSEU5
A
3 Screw BMZ26P140FTC BMZ26P160FTC
9 Chassis CNA3123 CNA3179
29 Grille Assy CXE2183 CXE3275
45 Grille Unit CXE2082 CXE3277
48 Screw ISS26P060FTC ASZ26P060FTC
49 Card CNW1231 Not used
Mark No. Description AVIC-F310BT/XSAU AVIC-F320BT/XSAU
B
3 Screw BMZ26P140FTC BMZ26P160FTC
9 Chassis CNA3123 CNA3179
29 Grille Assy CXE2183 CXE3275
45 Grille Unit CXE2082 CXE3277
48 Screw ISS26P060FTC ASZ26P060FTC
49 Card CNW1231 Not used
C
EXTERIOR(2)(Page 66)
EXTERIOR(2) SECTION PARTS LIST *:Non spare part
Mark No. Description AVIC-F310BT/XSEU5 AVIC-F320BT/XSEU5
1 Cord Assy CDP1246 CDP1331
2 Terminal Cover CKX-003 Not used
3 Detach Grille Assy CXE2188 CXE3272
18 TF-NAVI BOARD 541117230005 541117680002
D 19 TF-FRONT COVER KIT 541217230002 541217680001
Mark No. Description AVIC-F310BT/XSAU AVIC-F320BT/XSAU
1 Cord Assy CDP1247 CDP1332
3 Detach Grille Assy CXE2189 CXE3273
18 TF-NAVI BOARD 541117230006 541117680003
19 TF-FRONT COVER KIT 541217230002 541217680001
E
F
AVIC-F320BT/XSEU5
4
1 2 3 4
5 6 7 8
EXERIOR(3)(AVIC-F320BT/XSEU5)
A
B
C
EXTERIOR(3)(AVIC-F320BT/XSEU5) SECTION PARTS LIST
Mark No. Description Part No.
1 Screw BMZ30P060FTC
2 Screw CMZ50P060FTC
3 Holder CND3430
4 Holder CND3431
5 Panel CNU1288
D
E
F
AVIC-F320BT/XSEU5
5 6 7 8
