Image preview - the first page of the document
>> Download pioneer_avic-z2_hd3_crt3877_sm documenatation <<
Text preview - extract from the document
ORDER NO.
CRT3877
HDD MULTIMEDIA AV NAVIGATION SERVER
AVIC-Z2 /XU/UC
AVIC-HD3/XU/EW5
is a trademark of DVD Format/Logo Licensing Corporation.
This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model No. Order No. Mech. Module Remarks
AVIC-Z1/UC CRT3618
CX-3016 CRT3056 MS3 DVD Mech. Module:Circuit Description, Mech. Description, Disassembly
ND-BT1/E5 CRT3684 Bluetooth unit :
(ND-BT1/E is sold with AVIC-HD3/XU/EW5.)
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
K-ZZU. FEB. 2007 Printed in Japan
1 2 3 4
EXPLODED VIEWS AND PARTS LIST
PACKING(Page 10)
A
PACKING SECTION PARTS LIST *:Non spare part
Mark No. Description AVIC-Z1/UC AVIC-Z2/XU/UC
1-1 Owner's Manual CRB2183 CRB2295
1-2 Owner's Manual CRB2184 CRB2297
1-3 Owner's Manual/POC/FRE CRB2185 CRB2296
1-4 Owner's Manual/POC/FRE CRB2186 CRB2298
1-5 Owner's Manual CRB2258 CRB2299
1-6 Owner's Manual/POC/FRE CRB2259 CRB2300
1-13 Installation Manual CRD4100 CRD4153
B
* 1-14 Registration Card CRY1245 CRY1263
* 1-25 Card ARY1048 CRY1246(Warranty Card)
2 Cover CEG1177 CEG1383
3 Carton CHG5732 CHG6069
4 Contain Box CHL5732 CHL6069
5 Protector(Upper) CHP2227 CHP2782
6 Protector CHP2242 CHP3181
7 Protector CHP2272 CHP2783
C 10 Cord Assy CDE8083 CDP1045
23 Sub Carton CHA3298 CHG5691
24 Panel CNS8669 CNS9008
34 Cord Assy CDE8082 CDP1047
D
E
F
2 AVIC-Z2/XU/UC
1 2 3 4
5 6 7 8
Mark No. Description AVIC-HD1BT/EW5 AVIC-HD3/XU/EW5
1-1 Owner's Manual/PEE/ENG CRB2187 CRB2301
A
1-2 Owner's Manual/PEE/ENG CRB2188 CRB2307
1-3 Owner's Manual/PEE/SPE CRB2189 CRB2302
1-4 Owner's Manual/PEE/SPE CRB2190 CRB2308
1-5 Owner's Manual/PEE/GER CRB2191 CRB2303
1-6 Owner's Manual/PEE/GER CRB2192 CRB2309
1-7 Owner's Manual/PEE/FRE CRB2193 CRB2304
1-8 Owner's Manual/PEE/FRE CRB2194 CRB2310
1-9 Owner's Manual/PEE/ITA CRB2195 CRB2305
1-10 Owner's Manual/PEE/ITA CRB2196 CRB2311 B
1-11 Owner's Manual/PEE/DUT CRB2197 CRB2306
1-12 Owner's Manual/PEE/DUT CRB2198 CRB2312
1-13 Installation Manual CRD4101 CRD4154
* 1-16 Passport CRY1013 Not used
1-18 Owner's Manual/PEE/ENG CRB2260 CRB2313
1-19 Owner's Manual/PEE/SPE CRB2261 CRB2314
1-20 Owner's Manual/PEE/GER CRB2262 CRB2315
1-21 Owner's Manual/PEE/FRE CRB2263 CRB2316 C
1-22 Owner's Manual/PEE/ITA CRB2264 CRB2317
1-23 Owner's Manual/PEE/DUT CRB2265 CRB2318
2 Cover CEG1074 CEG1382
3 Carton CHG5899 CHG6070
4 Contain Box CHL5899 CHL6070
5 Protector(Upper) CHP2227 CHP3319
6 Protector CHP2242 CHP3181
D
7 Protector CHP2272 CHP3320
10 Cord Assy CDE8083 CDP1045
12 Cord Assy CDE8165 CDP1046
13 Screw Assy CEA3797 CEA7395
16 Screw CMZ50P060FTC(x8) CMZ50P060FTC(x4)
23 Sub Carton CHA3298 CHG5691
24 Panel CNS8669 CNS8665
35 Protector Not used CHP3321
36 Protector Not used CHP3322 E
37 Screw Not used CBA2081
38 Bush Not used CNV3930
* 39 Polyetylene Bag Not used E36-615
40 Panel Not used CNS9007
F
AVIC-Z2/XU/UC 3
5 6 7 8
1 2 3 4
A
2
35
40
39
B
37
38
36
C
EXTERIOR(1)(Page 12)
EXTERIOR(1) SECTION PARTS LIST
Mark No. Description AVIC-Z1/UC AVIC-Z2/XU/UC
5 Screw(M3 x 10) CBA1637 CBA2097
82 Panel Unit CXC5925 CXC7880
Mark No. Description AVIC-HD1BT/EW5 AVIC-HD3/XU/EW5
5 Screw(M3 x 10) CBA1637 CBA2097
82 Panel Unit CXC5984 CXC7980
D
94 Screw Not used CMZ50P060FTC
95 Holder Not used CND3430
96 Holder Not used CND3431
97 Screw Not used BMZ30P060FTC
94
E 96
96
97 94
97
97
F 95
97
4 AVIC-Z2/XU/UC
1 2 3 4
5 6 7 8
A
EXTERIOR(2)(Page 14)
EXTERIOR(2) SECTION PARTS LIST
Mark No. Description AVIC-Z1/UC AVIC-Z2/XU/UC
4 Screw(M2 x 3) CBA1527 CBA2096
61 CC Unit CWN1582 CWN2449
71 HDD Assy(Service) CXX2121 CXX2207
Mark No. Description AVIC-HD1BT/EW5 AVIC-HD3/XU/EW5
B
4 Screw(M2 x 3) CBA1527 CBA2096
61 CC Unit CWN1632 CWN2450
69 Chassis Unit CXC6523 CXC8128
71 HDD Assy(Service) CXX2122 CXX2208
EXTERIOR(3)(Page 16)
EXTERIOR(3) SECTION PARTS LIST
Mark No. Description AVIC-Z1/UC AVIC-Z2/XU/UC
2 Cap CNS1472 Not used
C
3 Cord Assy CDE8083 CDP1045
22 Grille CNS8523 CNS9018
25 Lighting Conductor CNV8732 CNV9510
51 Cord Assy CDE8082 CDP1047
Mark No. Description AVIC-HD1BT/EW5 AVIC-HD3/XU/EW5
2 Cap CNS1472 Not used
3 Cord Assy CDE8083 CDP1045
7 Cord Assy CDE8165 CDP1046 D
22 Grille CNS8540 CNS9004
25 Lighting Conductor CNV8732 CNV9510
E
F
AVIC-Z2/XU/UC 5
5 6 7 8
1 2 3 4
ELECTRICAL PARTS LIST(Page 121)
A GPS UNIT
AVIC-Z1/UC AVIC-Z2/XU/UC
Circuit Symbol and No. Part Name
AVIC-HD1BT/EW5 AVIC-HD3/XU/EW5
L402 Inductor CTF1486 LCYC1R2K1608
L403 Inductor CTF1486 LCYC1R2K1608
AUDIO UNIT
Circuit Symbol and No. Part Name AVIC-Z1/UC AVIC-Z2/XU/UC
Q1006 Transistor DTC114EU DTC114EUA
B
Q1201 Transistor DTC114EU DTC114EUA
Q1203 Transistor DTC114EU DTC114EUA
Q1431 Transistor DTC114EU DTC114EUA
Q1521 Transistor DTC114EU DTC114EUA
Q1852 Transistor DTC114EU DTC114EUA
Circuit Symbol and No. Part Name AVIC-HD1BT/EW5 AVIC-HD3/XU/EW5
Q1006 Transistor DTC114EU DTC114EUA
C
Q1201 Transistor DTC114EU DTC114EUA
Q1203 Transistor DTC114EU DTC114EUA
Q1431 Transistor DTC114EU DTC114EUA
Q1521 Transistor DTC114EU DTC114EUA
Q1823 Transistor DTC114EU DTC114EUA
Q1852 Transistor DTC114EU DTC114EUA
Q2501 Transistor DTC124EU DTC124EUA
Q2502 Transistor DTC124EU DTC124EUA
D Q2503 Transistor DTC124EU DTC124EUA
Q2504 Transistor DTC124EU DTC124EUA
E
F
6 AVIC-Z2/XU/UC
1 2 3 4
5 6 7 8
NAVI MOTHER UNIT
AVIC-Z1/UC AVIC-Z2/XU/UC
Circuit Symbol and No. Part Name
AVIC-HD1BT/EW5 AVIC-HD3/XU/EW5
A
Q5003 Transistor DTC114EU DTC114EUA
Q5004 Transistor DTC114EU DTC114EUA
Q5483 Transistor DTC114EU DTC114EUA
Q5651 Transistor 2SA1576 2SA1576A
Q5902 Transistor DTC114EU DTC114EUA
Q5921 Transistor 2SA1576 2SA1576A
Q6201 Transistor DTC114EU DTC114EUA
Q6204 Transistor DTC114EU DTC114EUA
Q6251 Transistor DTC114EU DTC114EUA B
Q6301 Transistor 2SA1576 2SA1576A
Q6302 Transistor DTC114EU DTC114EUA
Q6311 Transistor 2SA1576 2SA1576A
Q6312 Transistor DTC114EU DTC114EUA
Q6351 Transistor DTC114EU DTC114EUA
Q6352 Transistor DTC114EU DTC114EUA
Q6355 Transistor DTC114EU DTC114EUA
C
Q6601 Transistor 2SA1576 2SA1576A
MONITOR UNIT
AVIC-Z1/UC AVIC-Z2/XU/UC
Circuit Symbol and No. Part Name
AVIC-HD1BT/EW5 AVIC-HD3/XU/EW5
Q352 Transistor 2SA1576 2SA1576A
D
E
F
AVIC-Z2/XU/UC 7
5 6 7 8
ORDER NO.
CRT3618
AVIC-Z1/UC
HDD MULTIMEDIA AV NAVIGATION SERVER
AVIC-Z1 /UC
AVIC-HD1BT /EW5
This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks
CX-3016 CRT3056 MS3 DVD Mech. Module:Circuit Descriptions, Mech. Descriptions, Disassembly
ND-BT1/E5 CRT3684 Bluetooth unit
(ND-BT1/E is sold as packed unit of AVIC-HD/BT/EW5 in EW area.)
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
K-ZZU.MAR. 2006 Printed in Japan
1 2 3 4
SAFETY INFORMATION
UC
A CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the .
If you are not qualified to the repair of this product properly and , you should not risk trying to do so
WARNING
W
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
Health & Safety Code Section 25249.6 - Proposition 65
This product contains mercury. Disposal of this material may be regulated due to environmental considerations.
For disposal or recycling information, please contact your local authorities or the Electronics Industries
Alliance: www.eiae.org.
