Image preview - the first page of the document



>> Download DEH-17-CRT3513 documenatation <<

Text preview - extract from the document

                                                                                                                 ORDER NO.
                                                                                                               CRT3513

HIGH POWER CD PLAYER WITH FM/AM TUNER



DEH-17                                                             /XN/UC



This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).

        Model No.          Order No.    Mech. Module                                 Remarks

 DEH-1700/XN/UC            CRT3376

 CX-3110                   CRT3178     S10.1            CD Mech. Module : Circuit Description, Mech. Description, Disassembly




PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2005
                                                                                             K-ZZW. AUG. 2005 Printed in Japan
                   1                             2                               3                               4


        SAFETY INFORMATION
         WARNING
A
         This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
         California to cause cancer, birth defects or other reproductive harm.
         Health & Safety Code Section 25249.6 - Proposition 65




        EXPLODED VIEWS AND PARTS LIST
        PACKING(Page 8)
B       - PACKING SECTION PARTS LIST
        Mark No.                   Description             DEH-1700/XN/UC                  DEH-17/XN/UC
              12       Carton                        CHG5420                         CHG5579
              13       Contain Box                   CHL5349                         CHL5579
             16-1      Owner's Manual                CRD3906                         CRD4003
             16-3      Installation Manual           CRD3907                         CRD4004


        EXTERIOR(Page 10)
        - EXTERIOR SECTION PARTS LIST
C
        Mark No.                   Description              DEH-1700/XN/UC                 DEH-17/XN/UC
              9        Tuner Amp Unit                 CWM9604                        CWN1394
              25       Detach Grille Assy             CXC3540                        CXC5517
              26       Screw                          BPZ20P100FZK                   BPZ20P100FTB
              43       Grille Unit                    CXC3593                        CXC5480
              55       Screw                          IMS20P030FZK                   IMS20P030FTB




D
        ELECTRICAL PARTS LIST(Page 38)
        TUNER AMP UNIT
                       Circuit Symbol and No.               DEH-1700/XN/UC                  DEH-17/XN/UC
        IC302 IC                                      TDA7386                        PAL007B
        IC551 IC                                      TPD1018F                       Not used
        IC652 IC                                      TC7SET08FU                     TC7SET08FUS1
        C311                                          CEJQ2R2M50                     Not used
        C551, 552                                     CKSRYB103K50                   Not used
E




F




    2                                                     DEH-17/XN/UC
                   1                             2                               3                              4
