Image preview - the first page of the document

>> Download crt3790_deh_m3067zy_192 documenatation <<

Text preview - extract from the document

DAIHATSU

ORDER NO.
CRT3790
DEH-M3067ZY/XU/EW

COMBINATION CAR STEREO

DEH-M3067ZY /XU/EW

This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks

CX-3158 CRT3394 S10.1AAC CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly

PRODUCED
VEHICLE DESTINATION OEM PARTS No. ID No. PIONEER MODEL No.
AFTER

COO EUROPE October 2006 86180-B1080-B0 ----- DEH-M3067ZY/XU/EW

For details, refer to "Important Check Points for Good Servicing".

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
K-ZZD.AUG. 2006 Printed in Japan
1 2 3 4

SAFETY INFORMATION

A
- Service Precaution
1. You should conform to the regulations governing
the product (safety, radio and noise, and other
regulations), and should keep the safety during
servicing by following the safety instructions
described in this manual.
2. Before disassembling the unit, be sure to turn off
the power. Unplugging and plugging the connectors
during power-on mode may damage the ICs inside
the unit.
3. To protect the pickup unit from electrostatic discharge
during servicing, take an appropriate treatment
B (shorting-solder) by referring to "the DISASSEMBLY".
4. After replacing the pickup unit, be sure to check the
grating.
5. Be careful in handling ICs. Some ICs such as MOS
type are so fragile that they can be damaged by
electrostatic induction.
6. When this CD core unit is replaced, solder the land
at LCM-LCMM and LCP-LCPP beforehand.

Soldering

C M2
LOADING
/CARRIAGE
MOTOR

M1
SPINDLE
MOTOR REFO1

M1 CXB6007
SPINDLE MOTOR
S

C
PICKUP UNIT(P10)(SERVICE)

D C

HOME
M2 CXB8933 A CN???
LOADING
/CARRIAGE
MOTOR

DEH-M3067ZY/XU/EW
2
1 2 3 4
5 6 7 8

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely A
repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.

- Safety Precautions for those who Service this Unit.
