Image preview - the first page of the document
>> Download crt3070_deh_p5530mp_104 documenatation <<
Text preview - extract from the document
Service
Manual ORDER NO.
CRT3070
MULTI-CD CONTROL HIGH POWER CD/MP3/WMA PLAYER WITH RDS TUNER
DEH-P5530MP X1P/EW
DEH-P5500MP X1P/EW
- This service manual should be used together with the manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual, refer to the following
manual(s).
Model No. Order No. Mech. Module Remarks
DEH-P5530MP/XN/EW CRT3003
CX-3057 CRT3026 S10MP3 CD Mech. Module:Circuit Description, Mech.Description, Disassembly
PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2003 K-ZZA. FEB. 2003 Printed in Japan
1 2 3 4
A EXPLODED VIEWS AND PARTS LIST
PACKING(Page 6)
- PACKING SECTION PARTS LIST
* : Non spare part
Part No.
Mark No. Symbol and Description DEH-P5530MP/XN/EW DEH-P5530MP/X1P/EW
2 Accessory Assy CEA3376 UEA3376
* 10 Polyethylene Bag CEG-158 UEG-019
15 Polyethylene Bag CEG-162 UEG-012
17 Carton CHG4945 UHG-181
B 18 Contain Box CHL4945 UHL-151
19 Protector CHP2663 UHP2663
20 Protector CHP2664 UHP2664
21-1 Owner's Manual CRD3716 URD-237
21-2 Owner's Manual CRD3717 URD-238
21-3 Owner's Manual CRD3718 URD-239
21-4 Installation Manual CRD3719 URD-240
* 21-5 Passport CRY1013 CRY1014
* 21-6 Warranty Card CRY1157 URY1087
22 Case Assy CXB3520 UXB-009
C
* : Non spare part
Part No.
Mark No. Symbol and Description DEH-P5500MP/XN/EW DEH-P5500MP/X1P/EW
2 Accessory Assy CEA3376 UEA3376
* 10 Polyethylene Bag CEG-158 UEG-019
15 Polyethylene Bag CEG-162 UEG-012
17 Carton CHG4940 UHG-180
18 Contain Box CHL4940 UHL-150
19 Protector CHP2663 UHP2663
20 Protector CHP2664 UHP2664
D
21-1 Owner's Manual CRD3716 URD-237
21-2 Owner's Manual CRD3717 URD-238
21-3 Owner's Manual CRD3718 URD-239
21-4 Installation Manual CRD3719 URD-240
* 21-5 Passport CRY1013 CRY1014
* 21-6 Warranty Card CRY1157 URY1087
22 Case Assy CXB3520 UXB-009
E
F
2 DEH-P5530MP/X1P/EW
1 2 3 4
5 6 7 8
EXTERIOR(Page 8) A
- EXTERIOR SECTION PARTS LIST
Part No.
Mark No. Symbol and Description DEH-P5530MP/XN/EW DEH-P5530MP/X1P/EW
8 Holder CNC8659 UNC8659
15 Tuner Amp Unit CWM8587 UWM8587
31 FM/AM Tuner Unit CWE1645 UWE1645
34 Detach Grille Assy CXC1172 UXC1172
48 Keyboard Unit CWM8796 UWM8796
57 Sub Grille Assy CXC1173 UXC1173
B
Part No.
Mark No. Symbol and Description DEH-P5500MP/XN/EW DEH-P5500MP/X1P/EW
8 Holder CNC8659 UNC8659
15 Tuner Amp Unit CWM8587 UWM8587
31 FM/AM Tuner Unit CWE1645 UWE1645
34 Detach Grille Assy CXB9671 UXB9671
48 Keyboard Unit CWM8602 UWM8602
57 Sub Grille Assy CXB9970 UXB9970
C
ELECTRICAL PARTS LIST(Page 44)
KEYBOARD UNIT
Part No.
Symbol and Description DEH-P5500MP/XN/EW DEH-P5500MP/X1P/EW
D 1930 LED CL-195PG-CD CL195PGCD
D 1931 LED CL-195PG-CD CL195PGCD
D 1932 LED CL-195PG-CD CL195PGCD
D 1935 LED CL-195PG-CD CL195PGCD D
D 1946 LED CL-195PG-CD CL195PGCD
D 1947 LED CL-195PG-CD CL195PGCD
E
F
DEH-P5530MP/X1P/EW 3
5 6 7 8
