Image preview - the first page of the document

>> Download PIONEER_FX-M2137ZSA_M2037ZSA_M2337ZSA_CRT3086_sm documenatation <<

Text preview - extract from the document

SAAB

Service
Manual FX-M2137ZSA/X1B/UC
ORDER NO.
CRT3086
HEAD UNIT(3 in 1)

FX-M2137ZSA X1B/UC

FX-M2037ZSA X1B/EW

FX-M2337ZSA X1B/ES

VEHICLE DESTINATION PRODUCED AFTER PART No. ID No. PIONEER MODEL No.
SAAB 9-5 U.S.A., CANADA September 2003 5374640 FX-M2137ZSA/X1B/UC
SAAB 9-5 EUROPE September 2003 5374632 FX-M2037ZSA/X1B/EW
SAAB 9-5 GENERAL AREA September 2003 5374665 FX-M2337ZSA/X1B/ES

- This service manual should be used together with the following manual(s):
Model No. Order No. Mech. Module Remarks
CX-1011 CRT2406 3L Cassette Mech. Module : Mech. Description, Disassembly
CX-3026 CRT2944 S10 CD Mech. Module : Circuit Description, Mech. Description, Disassembly

- Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.

For details, refer to "Important symbols for good services".

PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER CORPORATION 2003 K-ZZA. APR. 2003 Printed in Japan
1 2 3 4

A
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.

2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
B
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.

4. Shipping mode and shipping screws

To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.

5. Lubricants, glues, and replacement parts
C Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.

- CD Player Service Precautions
1. Before disassembling the unit, be sure to turn off the 3. After replacing the pickup unit, be sure to check the
power. Unplugging and plugging the connectors dur- grating.(See p.76.)
ing power-on mode may damage the ICs inside the
E unit.
2. To protect the pickup unit from electrostatic dis-
charge during serviving, take an appropriate treat-
ment(shorting-solder) by referring to "the DISAS-
SEMBLY" on page 79.

2 FX-M2137ZSA/X1B/UC
1 2 3 4
5 6 7 8

SAFETY INFORMATION
- FX-M2037ZSA/X1B/EW

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. A
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely
repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.

1. Safety Precautions for those who Service this Unit.
