Image preview - the first page of the document



>> Download AVX-MG2027ZF,MG2127ZF,MG2227ZF,MG2327ZF documenatation <<

Text preview - extract from the document

                                                    FORD




                                                                                                                ORDER NO.
                                                                                                              CRT2871
                                                            AVX-MG2027ZF/XN/UC

RECEIVER ASSY WITH NAVIGATION DISPLAY

AVX-MG2027ZF
RECEIVER ASSY WITH NAVIGATION DISPLAY
                                                                                                          XN/UC


AVX-MG2127ZF
RECEIVER ASSY WITH NAVIGATION DISPLAY
                                                                                 XN/UC


AVX-MG2227ZF
RECEIVER ASSY WITH NAVIGATION DISPLAY
                                                                                 XN/UC


AVX-MG2327ZF                                                                     XN/UC

This service manual should be used together with the following manual(s):
   Model No.       Order No.      Mech.Module                                     Remarks
CX-951           CRT2872          G2              CD Mech. module:Circuit Description, Mech.Description, Disassembly




            For details, refer to "Important symbols for good services".



PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2002                                                                   K-ZZD.SEPT. 2002.printed in Japan
             1                              2                        3                      4

     - CD Player Service Precautions
    1. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the con-
    nectors during power-on mode may damage the ICs inside the unit.
    2. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate
    treatment shorting-solder by referring to "the DISASSEMBLY" on page 116.
    3. After replacing the pickup unit, be sure to check the grating. (See p.105.)
A
                             PRODUCED
            VEHICLE                                  OEM PARTS No.       ID No.    PIONEER MODEL No.
                               AFTER

    LINCOLN LS              November 2002       3W4T-18K931-A1
