Image preview - the first page of the document
hfe_pioneer_a-10-k_20-k_30-k_service_en


>> Download hfe_pioneer_a-10-k_20-k_30-k_service_en documenatation <<

Text preview - extract from the document
                                                                         ORDER NO.
                                                                        RRV4297
                                                     A-30-K

INTEGRATED AMPLIFIER


A-30-K
A-30-S
A-20-K
A-20-S
A-20
A-10-K
A-10-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
        Model      Type              Power Requirement        Remarks

 A-30-K/-S      PWSYXE8   AC 220 V to 230 V

 A-20-K/-S      PWSYXE8   AC 220 V to 230 V

 A-20           CUXE      AC 120 V

 A-10-K/-S      SYXE8     AC 220 V to 230 V
                 1                                  2                                 3                                4

    SAFETY INFORMATION

A

    This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
    yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
    to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
    This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
B                                                                                Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or           (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
