Image preview - the first page of the document



>> Download hfe_pioneer_a-a6_a9_sx-a6_a9_mk2_service_en documenatation <<

Text preview - extract from the document

                                                                                                                          A9
                                                                                                                 VOLUME

                                                                                                INPUT SELECTOR
                                                    POWER
                                                                 STANDBY               DIRECT




                                                    OFF     ON   PHONES



                                                                                                                                          ORDER NO.
                                                                                                                                         RRV3941
                                                                           A-A9MK2-K

INTEGRATED AMPLIFIER


A-A9MK2-K
A-A6MK2-K
STEREO RECEIVER

SX-A9MK2-K
SX-A6MK2-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
  Model            Type                    Power Requirement                                                                   Remarks

A-A9MK2-K    SYXCN5             AC 220 V to 230 V

A-A6MK2-K    SYXCN5             AC 220 V to 230 V

SX-A9MK2-K    CUXCN             AC 120 V

SX-A6MK2-K    CUXCN             AC 120 V




    For details, refer to "Important Check Points for good servicing".
                 1                                     2                                             3                                                    4

    SAFETY INFORMATION

A


    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely,
    you should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
B   This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive
    harm.
                                                                         Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or                      (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
