Image preview - the first page of the document
>> Download avh-p5750+avh4900 documenatation <<Text preview - extract from the document ORDER NO.
CRT3426
AVH-P5750DVD/RC
AV RECEIVER/DVD PLAYER 6.5 INCH WIDE DISPLAY
AVH-P5750DVD /RC
AVH-P5750DVD/RD
AVH-P5750DVD/RI
This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks
CX-3078 CRT3257 MS-3V1 DVD Mech. Module:Circuit Description, Mech. Description, Disassembly
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D sysmbol
are trademarks of Dolby Laboratories.
"DTS" and "DTS Digital Surround" are registered trademarks of Digital Theater Systems,
Inc.
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2005
K-ZZD.MAR. 2005 Printed in Japan
1 2 3 4
SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
A Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
RC, RI
1. Safety Precautions for those who Service this Unit.
