Image preview - the first page of the document
![pioneer_ddj_sb3_qrt1022[X]](/pics/5e849b3080ced.gif)
>> Download pioneer_ddj_sb3_qrt1022[X] documenatation <<
Text preview - extract from the document
ORDER NO.
QRT1022
DDJ-SB3
DJ CONTROLLER
DDJ-SB3
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
DDJ-SB3 SXJ DC 5 V
DDJ-SB3 XJCN DC 5 V
THIS SERVICE MANUAL SHOULD BE USED TOGETHER WITH THE FOLLOWING MANUAL(S).
Model Order No. Remarks
DDJ-SB3 QRT1021 BLOCK DIAGRAM, EXPLODED VIEWS AND PARTS LIST etc.
Pioneer DJ Corporation 6F, Yokohama i-Mark Place, 4-4-5 Minatomirai, Nishi-ku, Yokohama, Kanagawa 220-0012 Japan
2018 Pioneer DJ Corporation
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
CAUTION
B Since the fuse may be in the neutral of the mains supply, disconnect the mains to de-energize the phase conductors.
C
D
E
F
2 DDJ-SB3
1 2 3 4
5 6 7 8
CONTENTS
SAFETY INFORMATION.......................................................................................................................................................... 2
10. SCHEMATIC DIAGRAM ...................................................................................................................................................... 4
10.1 OVERALL WIRING DIAGRAM ..................................................................................................................................... 4 A
10.2 MAIN ASSY (1/4) and HPJK ASSY .............................................................................................................................. 5
10.3 MAIN ASSY (2/4).......................................................................................................................................................... 6
10.4 MAIN ASSY (3/4).......................................................................................................................................................... 7
10.5 MAIN ASSY (4/4).......................................................................................................................................................... 8
10.6 DCK1 ASSY (1/2) ......................................................................................................................................................... 9
10.7 DCK1 ASSY (2/2) ....................................................................................................................................................... 10
10.8 PNL2 ASSY (1/2)........................................................................................................................................................ 11
10.9 PNL2 ASSY (2/2), HLD1 ASSY and HLD2 ASSY ...................................................................................................... 12
10.10 VOLTAGES / WAVEFORMS ..................................................................................................................................... 13
11. PCB CONNECTION DIAGRAM ........................................................................................................................................ 17
11.1 MAIN ASSY, HPJK ASSY, HLD1 ASSY and HLD2 ASSY.......................................................................................... 17
11.2 DCK1 ASSY................................................................................................................................................................ 19 B
11.3 PNL2 ASSY ................................................................................................................................................................ 21
12. PCB PARTS LIST .............................................................................................................................................................. 23
C
D
E
F
DDJ-SB3 3
5 6 7 8
4 3 2 1
DDJ-SB3 4
To PC
CN1001 CN101
VKN2097-A VKN2097-A
DDE1150-A
USB CABLE
V+5LED 39 1 V+5LED
GNDLED 38 2 GNDLED
GNDLED 37 3 GNDLED
LED0 36 4 LED0
DCS1111-A
MIC VR
VR701
GRID0 35 5 GRID0
F
LED1 34 6 LED1
GRID1 33 7 GRID1
LED2 32 8 LED2
GRID2 31 9 GRID2
GRID4 30 10 GRID4
GRID3 29 11 GRID3
GRID5 28 12 GRID5
LED_PLAY1 27 13 LED_PLAY1
GRID6 26 14 GRID6
LED_FX1-2 25 15 LED_FX1-2
GRID7 24 16 GRID7
LED_FX1-3 23 17 LED_FX1-3
KEY3 22 18 KEY3
DKN1669-A
JA701
MIC JACK
GNDD 21 19 GNDD
WHITE
KEY2 20 20 KEY2
1
39P FFC
GNDD 19 21 GNDD
AKF7002-A
L = 150 mm
DDD1771-A
KEY1 18 22 KEY1
SAME FACE
KN1201
GNDD 17 23 GNDD
TO JOG PLATE
KEY0 16 24 KEY0
GNDD 15 25 GNDD
JOG_DIAL1_1 14 26 JOG_DIAL1_1
KEY_FX1-1 13 27 KEY_FX1-1
JOG_DIAL1_0 12 28 JOG_DIAL1_0
KEY_FX1-2 11 29 KEY_FX1-2
V+3R3D 10 30 V+3R3D
KEY_FX1-3 9 31 KEY_FX1-3
JOG_TCH1 8 32 JOG_TCH1
L
GNDD 7 33 GNDD
GNDAD 6 34 GNDAD
AD_CRFD 5 35 AD_CRFD
AKB7181-A
R
MASTER
JA702
AD_TEMPO1_1 4 36 AD_TEMPO1_1
AD_FXLV1 3 37 AD_FXLV1
AD_TEMPO1_0 2 38 AD_TEMPO1_0
V+3R3AD 1 39 V+3R3AD
E
DIP
DIP
DIP
V+3R3AD
AD_CRFD
GNDAD
GNDFP1
4
3
2
1
51048-0400
BOARD IN
VERTICAL
VERTICAL
JH1001
JP1001
10. SCHEMATIC DIAGRAM
L = 50mm
LIGHT BLUE
D20PYY0405E
4P JUMPER WIRE
DIP
4
3
2
1
DKN1237-A
USB-Btype
JA101
USB JACK
51048-0400
BOARD IN
(DWX4133)
DCK1 ASSY
GNDAD
JH1201
GNDFP1
V+3R3AD
AD_CRFD
To CONTROLLER
C C 1/2- C 2/2
JP101
L = 200mm
LIGHT BLUE
D20PDY0520E
JH101
51048-0500
5P JUMPER WIRE
5 HP_L
4 GNDAH
3 HP_R
D
2 HP_MUTE
1 GNDAH
DIP
BOARD IN
(DWX4132)
MAIN ASSY
CN2001
VKN1256
CN103VKN1256
AD_TRIM1 1 1 AD_TRIM1
GNDAD 2 2 GNDAD
A A 1/4- A 4/4
AD_MLV 3 3 AD_MLV
AD_HI1 4 4 AD_HI1
DIP
2
5
4
3
1
AD_TEMPO2-1 5 5 AD_TEMPO2-1
AD_MID1 6 6 AD_MID1
52147-0510
HP_L
HP_R
AD_TEMPO2-0 7 7 AD_TEMPO2-0
VERTICAL
CN1601
GNDAH
GNDAH
AD_FLTR2 8 8 AD_FLTR2
AD_FXLV2 9 9 AD_FXLV2
AD_LOW2 10 10 AD_LOW2
AD_HI2 11 11 AD_HI2
GNDAH (HP_MUTE)
AD_MID2 12 12 AD_MID2
WHITE
25P FFC
AD_TRIM2 13 13 AD_TRIM2
XKN3017-B
AD_HPLV 14 14 AD_HPLV
L = 110 mm
DDD1851-A
JA1601
HP MINI JACK
AD_CFD1 15 15 AD_CFD1
GNDAD 16 16 GNDAD
REVERSE FACE
AD_CFD2 17 17 AD_CFD2
AD_FLTR1 18 18 AD_FLTR1
AD_LOW1 19 19 AD_LOW1
V+3R3AD 20 20 V+3R3AD
V+3R3AD 21 21 V+3R3AD
BROWSE_ENC1 22 22 BROWSE_ENC1
GNDD (GNDD_BRWS) 23 23 GNDD
C
BROWSE_ENC0 24 24 BROWSE_ENC0
GNDD (GNDD_BRWS) 25 2◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
