Image preview - the first page of the document



>> Download pioneer_djm-3000_sm documenatation <<

Text preview - extract from the document

                                                                                                            ORDER NO.
                                                                                                           RRV2587
                                                                DJM-3000

DJ MIXER


DJM-3000
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                                                                               The voltage can be converted by the
    Model             Type                      Porew Requirement
                                                                                        following method.

 DJM-3000       KUCXCN             AC120V
 DJM-3000       WYXCN              AC220-240V

 DJM-3000       RLBXCN             AC110-120V/220-240V                         With the voltage selector




For details, refer to "Important symbols for good services" on the next page.



PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2002
                                                                                           T-ZZR APR.2002.printed in Japan
                  1                                         2                                   3                                   4


    SAFTY INFORMATION
A


    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
    WARNING
B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
                                                                              Health & Safety Code Section 25249.6
