Image preview - the first page of the document



>> Download pioneer_efx-1000_rrv3122_sm documenatation <<

Text preview - extract from the document

                                                                                                         ORDER NO.
                                                                                                       RRV3122
                                                                EFX-1000

DJ EFFECTOR


EFX-1000
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model               Type                  Power Requirement                             Remarks

 EFX-1000        KUCXJ             AC120V

 EFX-1000        TLTXJ             AC110 - 240V

 EFX-1000        WYXJ              AC220 - 240V

 EFX-1000        WAXJ              AC220 - 240V




       For details, refer to "Important Check Points for good servicing".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2005
                                                                                        T-IZY JUNE 2005 printed in Japan
                1                                  2                                  3                                4

    SAFETY INFORMATION

A
    This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
    yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
    to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
    This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
B                                                                                Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or           (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
