Image preview - the first page of the document



>> Download PIONEER_FH-X830BHS_X730BS_X731BT_X730BT_X85BT_X89BT_CRT5823_[X] documenatation <<

Text preview - extract from the document

                                                                                                                   ORDER NO.
                                                                                                                CRT5823
                                                               FH-X830BHS/XNUC

CD RDS RECEIVER


FH-X830BHS                                                                                             /XNUC

FH-X730BS                                                     /XNUC

FH-X731BT                                                    /XNUC

FH-X730BT                                                    /XNEW5

FH-X785BT                                                    /XNES

FH-X789BT                                                    /XNID


This service manual should be used together with the following manual(s):
  Model No.      Order No.      Mech. Module                                      Remarks

CX-3287         CRT4759        S11.6STD           CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly




PIONEER CORPORATION 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo 113-0021, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 2 Jalan Kilang Barat, #07-01, Singapore 159346
  PIONEER CORPORATION 2016
                                                                                                K-ZZZ MAY 2016 Printed in Japan
                    1                                        2                            3                                4

    SAFETY INFORMATION
        CAUTION
A       This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
        Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
        complex products such as those covered by this manual.
        Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
        If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
        and refer the repair to a qualified service technician.
        WARNING
        This product may contain a chemical known to the State of California to cause cancer, or birth defects or
        other reproductive harm.
        Health & Safety Code Section 25249.6 - Proposition 65

B
        Where in a manufacturer's service documentation, for example in circuit diagrams or lists
        of components, a symbol is used to indicate that a specific component shall be replaced only
        by the component specified in that documentation for safety reasons, the following symbol shall
        be used:



        - Safety Precautions for those who Service this Unit.
          When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
          results.
        Caution:
          1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
C         2. During repair or tests, do not view laser beam for 10 seconds or longer.

           CAUTION:
           USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
           SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.


           CAUTION                                                Laser diode characteristics
           This product is a class 1 laser product classi-        Wave length : 785 nm to 814 nm
           fied under the Safety of laser products, IEC
           60825-1:2007.
                                                                  Maximum output : 1 190
