Image preview - the first page of the document
>> Download hfe_pioneer_n-30_50_service_en documenatation <<
Text preview - extract from the document
NETWORK AUDIO PLAYER N-50
/I STANDBY/ON
FUNCTION
STANDBY PURE AUDIO Hi-Bit32
iPod/USB
5V 2.1A
ORDER NO.
RRV4272
N-50
NETWORK AUDIO PLAYER
N-50
N-50-K
N-50-S
N-30
N-30-K
N-30-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
N-50 CUXE AC 120V
N-50-K SYXE8 AC 220V to 240V
N-50-S SYXE8 AC 220V to 240V
N-30 CUXE AC 120V
N-30-K SYXE8 AC 220V to 240V
N-30-S SYXE8 AC 220V to 240V
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION
K-FZV FEB. 2012 Printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
B Health & Safety Code Section 25249.6 - Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MOD◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
