Image preview - the first page of the document
hfe_pioneer_sc-75_1523_1528_lx57_service_pt10_rrv4461


>> Download hfe_pioneer_sc-75_1523_1528_lx57_service_pt10_rrv4461 documenatation <<

Text preview - extract from the document
                                                                                                           ORDER NO.
                                                                                                        RRV4461
                                                                   SC-75

AV RECEIVER


SC-75
SC-1528-K
SC-1523-K
SC-LX57
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
      Model                   Type                    Power Requirement                         Remarks
 SC-75                 CUXJ                 AC 120V
 SC-1528-K             CUXJ                 AC 120V
 SC-1523-K             UXJCB                AC 120V
 SC-LX57               JXJ                  AC 100V




THIS SERVICE MANUAL SHOULD BE USED TOGETHER WITH THE FOLLOWING MANUAL(S).
           Model No.                 Order No.                              Remarks
 SC-75, SC-1528-K, SC-1523-K         RRV4449      BLOCK DIAGRAM, EXPLODED VIEWS AND PARTS LIST etc.




                                                                                        K-FZV JULY 2013 Printed in Japan
                 1                                  2                                3                                4

    SAFETY INFORMATION

A



    This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
    yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
    to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
    This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
B   cause cancer, birth defects or other reproductive harm.
                                                                                 Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or           (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
