Image preview - the first page of the document
>> Download hfe_pioneer_sc-77_79_lx77_lx87_service_en_rrv4463_pt10 documenatation <<Text preview - extract from the document ORDER NO.
RRV4463
SC-79
AV RECEIVER
SC-79
SC-77
SC-LX87
SC-LX77
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
SC-79 CUXJ AC 120V
SC-77 CUXJ AC 120V
SC-LX87 JXJ AC 100V
SC-LX77 JXJ AC 100V
THIS SERVICE MANUAL SHOULD BE USED TOGETHER WITH THE FOLLOWING MANUAL(S).
Model No. Order No. Remarks
SC-79, SC-77 RRV4451 BLOCK DIAGRAM, EXPLODED VIEWS AND PARTS LIST etc.
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
B cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MOD
