Service Manuals, User Guides, Schematic Diagrams or docs for : Pioneer Audio SC-LX89-K RRV4617 - SC-99, SC-97, SC-LX89-K, SC-LX89-S, SC-LX79-K, SC-LX79-S

<< Back | Home

Most service manuals and schematics are PDF files, so You will need Adobre Acrobat Reader to view : Acrobat Download Some of the files are DjVu format. Readers and resources available here : DjVu Resources
For the compressed files, most common are zip and rar. Please, extract files with Your favorite compression software ( WinZip, WinRAR ... ) before viewing. If a document has multiple parts, You should download all, before extracting.
Good luck. Repair on Your own risk. Make sure You know what You are doing.



Image preview - the first page of the document



>> Download RRV4617 - SC-99, SC-97, SC-LX89-K, SC-LX89-S, SC-LX79-K, SC-LX79-S documenatation <<

Text preview - extract from the document

                                                                                                            ORDER NO.
                                                                                                         RRV4617
                                                                     SC-99

AV RECEIVER


SC-99
SC-97
SC-LX89-K
SC-LX89-S
SC-LX79-K
SC-LX79-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
       Model                  Type                       Power Requirement                       Remarks
 SC-99                 CUXJ                 AC 120V
 SC-97                 CUXJ                 AC 120V
 SC-LX89-K/-S          SYXJ8                AC 220V to 230V
 SC-LX79-K/-S          SYXJ8                AC 220V to 230V

THIS SERVICE MANUAL SHOULD BE USED TOGETHER WITH THE FOLLOWING MANUAL(S).
                Model No.                    Order No.                            Remarks
 SC-99, SC-97, SC-LX89-K/-S, SC-LX79-K/-S     ARP4004         SCHEMATIC DIAGRAM, PCB CONNECTION DIAGRAM




PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
   Onkyo & Pioneer Corporation 2015
                                                                                         K-FZV OCT. 2015 Printed in Japan
                 1                                  2                                3                                4

    SAFETY INFORMATION

A


    This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
    yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
    to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
    This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
B   cause cancer, birth defects or other reproductive harm.
                                                                                 Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or           (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
