VOLUME
INPUT SELECTOR
POWER
STANDBY DIRECT
OFF ON PHONES
ORDER NO.
RRV3941
A-A9MK2-K
INTEGRATED AMPLIFIER
A-A9MK2-K
A-A6MK2-K
STEREO RECEIVER
SX-A9MK2-K
SX-A6MK2-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
A-A9MK2-K SYXCN5 AC 220 V to 230 V
A-A6MK2-K SYXCN5 AC 220 V to 230 V
SX-A9MK2-K CUXCN AC 120 V
SX-A6MK2-K CUXCN AC 120 V
For details, refer to "Important Check Points for good servicing".
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely,
you should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive
harm.
Health & Safety Code Section 25249.6 - Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols (fast operating fuse) and/or (slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MOD
