Image preview - the first page of the document



>> Download hfe_pioneer_sx-lx70sw_service_rrv3674_en documenatation <<

Text preview - extract from the document

                                                                                                              ORDER NO.
                                                                                                          RRV3674
                                                                SX-LX70SW

AUDIO MULTI-CHANNEL RECEIVER SUBWOOFER


SX-LX70SW
ACCESSORY BOX

AS-LX70
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model             Type                     Power Requirement                                Remarks

  SX-LX70SW      KUCXTW             AC 120 V

  AS-LX70        XJ/UC              ---




This product is component of system.
                Component                            System              Service Manual                Remarks

  H5.1CH SURROUND SYSTEM                       HTS-LX70                       ---------

    AUDIO MULTI-CHANNEL RECEIVER SUBWOOFER     SX-LX70SW/KUCXTW             RRV3674             This manual

    ACCESSORY BOX                              AS-LX70/XJ/UC                RRV3674             This manual

    SATELLITE SPEAKER                          SSP-LX70ST/XTW/WL5           RRV3658




       For details, refer to "Important Check Points for good servicing".


PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936


                                                                                          T-ZZV SEPT. 2007 printed in Japan
                1                                  2                                 3                                4

    SAFETY INFORMATION

A

    This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
    yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
    to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
    This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
B                                                                                Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or            (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
