Image preview - the first page of the document



>> Download pioneer_pdp-r06fe_pdp-r06xe_arp3275 documenatation <<

Text preview - extract from the document

                                                                                                          ORDER NO.
                                                                                                        ARP3275
                                                                PDP-R06XE

MEDIA RECEIVER


PDP-R06XE
PDP-R06FE
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model               Type                    Power Requirement                            Remarks

 PDP-R06XE       WYVIXK5           AC220-240V

 PDP-R06FE       WYVI5             AC220-240V

 PDP-R06FE       WYVIXK5           AC220-240V




This service manual should be used together with the following manual(s).
            Model No.                Order No.                                 Remarks
 PDP-R06XE, PDP-R06FE                 ARP3276       SCHEMATIC DIAGRAM, PCB CONNECTION DIAGRAM




       For details, refer to "Important Check Points for good servicing".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2005
                                                                                         T-IZR AUG. 2005 printed in Japan
                   1                                        2                                 3                                 4

    SAFETY INFORMATION

A


        This service manual is intended for qualified service technicians; it is not meant for the casual
        do-it-yourselfer. Qualified technicians have the necessary test equipment and tools,and have been
        trained to properly and safely repair complex products such as those covered by this manual.
        Improperly performed repairs can adversely affect the safety and reliability of the product and may
        void the warranty. If you are not qualified to perform the repair of this product properly and safely you ,
        should not risk trying to do so and refer the repair to a qualified service technician.
        WARNING
B       This product contains and certain electrical parts contain chemicals which are known to the state of California to cause cancer,
        birth defects or other reproductive harm.
                                                                                       Health & Safety CodeSection 25249.6
