Image preview - the first page of the document
>> Download PRV-LX10 user manual documenatation <<
Text preview - extract from the document
DVD recorder
PRV-LX10
Operating Instructions
IMPORTANT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, CAUTION: The exclamation point within an equilateral
within an equilateral triangle, is intended to TO PREVENT THE RISK OF ELECTRIC triangle is intended to alert the user to the
alert the user to the presence of uninsulated SHOCK, DO NOT REMOVE COVER (OR presence of important operating and
"dangerous voltage" within the product's BACK). NO USER-SERVICEABLE PARTS maintenance (servicing) instructions in the
enclosure that may be of sufficient INSIDE. REFER SERVICING TO QUALIFIED literature accompanying the appliance.
magnitude to constitute a risk of electric SERVICE PERSONNEL.
shock to persons.
D3-4-2-1-1_En-A
Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified
service personnel.
The cut-off plug should be disposed of and must The wire which is coloured brown must be
IMPORTANT not be inserted into any 13 amp socket as this can
result in electric shock. The plug or adaptor or the
connected to the terminal which is marked with the
letter L or coloured red.
distribution panel should be provided with 5 A fuse.
FOR USE IN THE UNITED As the colours of the wires in the mains lead of this NOTE
KINGDOM. appliance may not correspond with coloured After replacing or changing a fuse, the fuse cover in
The wires in this mains lead are coloured in markings identifying the terminals in your plug, the plug must be replaced with a fuse cover which
accordance with the following code: proceed as follows ; corresponds to the colour of the insert in the base
Green and Yellow : Earth The wire which is coloured green and yellow must of the plug or the word that is embossed on the
Blue : Neutral be connected to the terminal in the plug which is base of the plug, and the appliance must not be
Brown : Live marked with the letter E or by the earth symbol , used without a fuse cover. If lost replacement fuse
If the plug provided is unsuitable for your socket or coloured green or green and yellow. covers can be obtained from your dealer.
outlets, the plug must be cut off and a suitable plug The wire which is coloured blue must be connected Only 5 A fuses approved by B.S.I or A.S.T.A to
fitted. to the terminal which is marked with the letter N or B.S.1362 should be used.
coloured black. D3-4-2-1-2-1_En
WARNING
This equipment is not waterproof. To prevent a fire VENTILATION CAUTION
or shock hazard, do not place any container filed When installing this unit, make sure to leave space
with liquid near this equipment (such as a vase or around the unit for ventilation to improve heat
flower pot) or expose it to dripping, splashing, rain radiation (at least 5 cm at top, 5 cm at rear, and 5
or moisture. D3-4-2-1-3_A_En cm at each side).
WARNING
WARNING Slots and openings in the cabinet are provided for
Before plugging in for the first time, read the following ventilation to ensure reliable operation of the
section carefully. product, and to protect it from overheating. To
The voltage of the available power supply differs prevent fire hazard, the openings should never be
according to country or region. Be sure that the blocked or covered with items (such as newspapers,
power supply voltage of the area where this unit table-cloths, curtains) or by operating the
will be used meets the required voltage (e.g., 230V equipment on thick carpet or a bed. D3-4-2-1-7b_A_En
or 120V) written on the rear panel. D3-4-2-1-4_A_En
Operating Environment
WARNING Operating environment temperature and humidity:
