Image preview - the first page of the document
>> Download trt1154_se_cn25dn__se_mj7_124 documenatation <<
Text preview - extract from the document
ORDER NO.
TRT1154
SE-CN25DN-Z1
STEREO HEADPHONES
SE-CN25DN-Z1 ZCEW5
SE-CN25DN-Z2 ZCEW5
SE-MJ7NC XZC/EW5
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
T-ZZA JUNE 2007 printed in Japan
1 2 3 4
1. SPECIFICATIONS
Model Frequency Maximum Sensitivity Weight
Impedance Driver unit Plug Cord
A responce Input power (Without cord)
24 (ON) 103 dB (ON1)
SE-MJ7NC 20 Hz to 20 000 Hz 100 mW 40 mm L/L 1.5 m, 3.5 m 200 g
52 (OFF) 100 dB (OFF)
SE-CN25DN- 18 Hz to 22 000 Hz 16 100 mW 106 dB 13.5 mm S 0.7 m 6g
MODEL : The column of is a color sign. (Z1:Black, Z2:White)
Plug form : S (straight type) / L (L type)
B
2. EXPLODED VIEWS AND PARTS LIST
NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
2.1 FOR SE-CN25DN-Z1/ZCEW5
EXPLODED VIEW PACKING VIEW PARTS LIST
1 3 Mark No. Description Part No.
C 1 Ring WNK2406
2 Cover WNK2409
3 Ear Pad WNV1123
2
D
2.2 FOR SE-CN25DN-Z2/ZCEW5
EXPLODED VIEW PACKING VIEW PARTS LIST
1 3
Mark No. Description Part No.
1 Ring WNK2770
2 Cover WNK2771
3 Ear Pad WNV1138
E
2
F
2 SE-CN25DN-Z1
1 2 3 4
5 6 7 8
2.3 FOR SE-MJ7NC/XZC/EW5
EXPLODED VIEW PACKING VIEW PARTS LIST
Mark No. Description Part No.
A
1 Ear Pad WNV1137
2 Cord Assy WDE1289
1
3 Cord Assy WDE1304
4 Pulg Adapter WKX1039
5 Pulg Adapter WKX1040
2
B
3
5
4
C
D
E
F
SE-CN25DN-Z1 3
5 6 7 8
