Image preview - the first page of the document



>> Download trt1156_se_m390_701 documenatation <<

Text preview - extract from the document

                                                                                                          ORDER NO.
                                                                                                        TRT1156
                                                                 SE-M390

STEREO HEADPHONES


SE-M390                                                                         XZC/EW5

SE-M290                                        XZC/EW5




PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2008
                                                                                        T-ZZA JAN. 2008 Printed in Japan
                    1                                    2                                  3                                   4

    1. SPECIFICATIONS

A                          Frequency                     Maximum                                                                    Weight
        Model                               Impedance               Sensitivity Driver unit           Plug          Cord
                            responce                    Input power                                                             (Without cord)

    SE-M390             5 Hz to 29 000 Hz    32 ohm      1 500 mW       105 dB
