Image preview - the first page of the document
>> Download trt1158_se_clx9_836 documenatation <<
Text preview - extract from the document
ORDER NO.
TRT1158
SE-CLX9
STEREO HEADPHONES
SE-CLX9 XZC/EW5
SE-CLX7 XZC/EW5
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
T-ZZA JAN. 2008 Printed in Japan
1 2 3 4
1. SPECIFICATIONS
A Frequency Maximum Weight
Model Impedance Sensitivity Driver unit Plug Cord
responce Input power (Without cord)
-
SE-CLX9 20 Hz to 20 000 Hz 32 ohm 100 mW 105 dB S/L 0.8 m, 0.7 m 8g
(Balanced armature)
-
SE-CLX7 20 Hz to 20 000 Hz 32 ohm 100 mW 105 dB S/L 0.8 m, 0.7 m 8g
(Balanced armature)
Plug form : S (straight type) / L (L type)
2. EXPLODED VIEWS AND PARTS LIST
B NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
2.1 FOR SE-CLX9
Exploded View Packing View SE-CLX9 Parts List
Mark No. Description Part No.
1 Extension Cord WDE1308
2 Ring WLA1032
3 1..Nozzle Set WXX1371
C
2..Nozzle Hi2 L/R Assy ........
2..Nozzle Hi1 L/R Assy ........
2..Nozzle Std L/R Assy ........
2..Nozzle Bass1 L/R Assy ........
2..Nozzle Bass2 L/R Assy ........
4 1..Chip Set WXX1373
2..Tip S ........
2..Tip M ........
2..Tip L ........
2..Tip LL ........
5 1..Holder Set WXX1372
1 2..Cover-S L/R ........
D
4 2..Cover-M L/R ........
2..Cover-L L/R ........
2 2..Cover-LL L/R ........
3
5
E
F
2 SE-CLX9
1 2 3 4
5 6 7 8
2.2 FOR SE-CLX7
Exploded View Packing View SE-CLX7 Parts List
A
Mark No. Description Part No.
1 Extension Cord WDE1308
2 1..Chip Set WXX1373
2..Tip S ........
2..Tip M ........
2..Tip L ........
2..Tip LL ........
3 1..Holder Set WXX1372
2..Cover-S L/R ........
2..Cover-M L/R ........
2..Cover- L L/R ........ B
2..Cover- LL L/R ........
1 2
C
3
D
E
F
SE-CLX9 3
5 6 7 8
