Image preview - the first page of the document

>> Download PIONEER_S-51W_RRV3971 documenatation <<

Text preview - extract from the document

ORDER NO.
RRV3971
S-51W

POWERED SUBWOOFER

S-51W
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks

S-51W SYXJ8 AC 220 V to 240 V

S-51W AXJ5 AC 220 V to 240 V

S-51W DFXJ AC 110 V to 127 V
S-51W DLPXJ AC 220 V to 240 V

For details, refer to "Important Check Points for good servicing".

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2009
T-IZA JULY 2009 Printed in Japan
1 2 3 4

A
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures.
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.

1 Use specified parts for repair.

Use genuine parts. Be sure to use important parts for safety.

2 Do not perform modifications without proper instructions.
B
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.

3 Make sure the soldering of repaired locations is properly performed.

When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)

4 Make sure the screws are tightly fastened.

Please be sure that all screws are fastened, and that there are no loose screws.

5 Make sure each connectors are correctly inserted.

Please be sure that all connectors are inserted, and that there are no imperfect insertion.
C
6 Make sure the wiring cables are set to their original state.

Please replace the wiring and cables to the original state after repairs.
In addition, be sure that there are no pinched wires, etc.

7 Make sure screws and soldering scraps do not remain inside the product.

Please check that neither solder debris nor screws remain inside the product.

8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.

Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.

9 There should be no spark traces or similar marks on the power plug.
D
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.

a Safe environment should be secured during servicing.

When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.

2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.

E 3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied.

4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.

5. Shipping mode and Shipping screws

F To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.

2 S-51W
1 2 3 4
5 6 7 8

CONTENTS
1. SERVICE PRECAUTIONS .................................................................................................................................................... 4
1.1 NOTES ON SOLDERING ............................................................................................................................................... 4
2. SPECIFICATIONS................................................................................................................................................................. 5 A
2.1 SPECIFICATIONS .......................................................................................................................................................... 5
2.2 PANEL FACILITIES......................................................................................................................................................... 6
3. BASIC ITEMS FOR SERVICE .............................................................................................................................................. 7
3.1 PCB LOCATIONS ........................................................................................................................................................... 7
4. BLOCK DIAGRAM ................................................................................................................................................................ 8
4.1 OVERALL WIRING DIAGRAM ....................................................................................................................................... 8
4.2 BLOCK DIAGRAM ........................................................................................................................................................ 10
5. DIAGNOSIS ........................................................................................................................................................................ 12
6. SERVICE MODE ................................................................................................................................................................. 12
7. DISASSEMBLY ................................................................................................................................................................... 12
8. EACH SETTING AND ADJUSTMENT ................................................................................................................................ 13
9. EXPLODED VIEWS AND PARTS LIST............................................................................................................................... 14 B
9.1 PACKING SECTION ..................................................................................................................................................... 14
9.2 EXTERIOR SECTION .................................................................................................................................................. 16
9.3 CHASSIS SECTION ..................................................................................................................................................... 18
10. SCHEMATIC DIAGRAM .................................................................................................................................................... 20
10.1 JACK ASSY ................................................................................................................................................................ 20
10.2 AMP ASSY ................................................................................................................................................................. 22
10.3 REGULATOR ASSY ................................................................................................................................................... 24
10.4 SUB TRANS and LED ASSYS ................................................................................................................................... 26
11. PCB CONNECTION DIAGRAM ........................................................................................................................................ 28
11.1 JACK ASSY ................................................................................................................................................................ 28
11.2 AMP ASSY ................................................................................................................................................................. 30
C
11.3 SUB TRANS and LED ASSYS ................................................................................................................................... 32
11.4 REGULATOR ASSY ................................................................................................................................................... 34
12. PCB PARTS LIST .............................................................................................................................................................. 35

S-51W 3
5 6 7 8
1 2 3 4

1. SERVICE PRECAUTIONS
1.1 NOTES ON SOLDERING
