Image preview - the first page of the document



>> Download rrv3616_s_dv363_158 documenatation <<

Text preview - extract from the document

                                                                                                       Subwoofer
                                                                      Front         Surround




                                                                                Center


                                                                                                                                            ORDER NO.
                                                                                                                                         RRV3616
                                                                                         S-DV363

SPEAKER SYSTEM


S-DV363                                                                                                            XJC/E, XJC/NC




1. REASSEMBLY AND DISASSEMBLY PRECAUTIONS
    1.1 FRONT/SURROUND SPEAKER 1.3 SUBWOOFER
         The grille is attached to the cabinet by 4 external screws.
                                                                                         The rear base is attached to the cabinet by 2 external screws.
         The speaker unit, together with the grille, is attached to the                  To detach it, unfasten those screws.
         cabinet by 4 external screws.
                                                                                         The speaker unit is attached to the baffle board by 4 external
         To detach it, first grille those speaker unit.                                  screws. To detach it, unfasten those screws.
         Next remove the cabinet and connecting cord .                                   When attaching it, face terminal rightward.
         When attaching it, so that terminal board of speaker unit
         turns to an input terminal side of cabinet hardware.

     1.2 CENTER SPEAKER
          The grille assy is attached to the cabinet by 8 external screws.
          The speaker unit, together with the grille assy, is attached to the
          cabinet by 4 external screws. To detach it, first remove the
          speaker unit. Next remove the cabinet. Then remove the
          connecting cord.
          When attaching it, so that terminal board of speaker unit
          turns to an input terminal side of cabinet hardware.



PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2007
                                                                                                                      T-ZZR JUNE 2007 Printed in Japan
               1                                2                               3                                4

    2. EXPLODED VIEWS AND PARTS LIST
        NOTES :
