>> Download pioneer_s-ew5 documenatation <<Text preview - extract from the document STANDBY/ON
POWER
VOLUME
MIN MAX
POWERED SUBWOOFER
ORDER NO.
RRV3264
S-EW5
POWERED SUBWOOFER
S-EW5
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
The voltage can be converted by
Model Type Porew Requirement
the following method.
S-EW5 DDFXTW AC 110-127V/220-230V/240V~ with the voltage selector
S-EW5 DLTXTW AC 110-127V/220-230V/240V~ with the voltage selector
