Image preview - the first page of the document



>> Download PIONEER_S-VW02_RRV2805 documenatation <<

Text preview - extract from the document

                                                                  STANDBY/ON
                                                                    POWER      CROSSOVER   VOLUME




                                                                                                                                 ORDER NO.
                                                                                                                                RRV2805
                                                                 S-VW02

POWERED SPEAKER SYSTEM


S-VW02
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
                                                                                                    The voltage can be converted by the
    Model             Type                    Porew Requirement
                                                                                                             following method.

 S-VW02         DDFXJI             AC110-127V/220-230V/240V~                                        with the voltage selector




  For details, refer to "Important symbols for good services".



PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2003
                                                                                                               T-ZZV JUNE 2003 printed in Japan
               1                                         2                                      3                                   4


    SAFETY INFORMATION
A



    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
    WARNING
B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
                                                                              Health & Safety Code Section 25249.6
