Image preview - the first page of the document
hfe_pioneer_vsx-1016v_1016txv_80txv_service


>> Download hfe_pioneer_vsx-1016v_1016txv_80txv_service documenatation <<

Text preview - extract from the document
                                                                                            ORDER NO.
                                                                                          RRV3401
                                                           VSX-1016V-K

AUDIO/VIDEO MULTI-CHANNEL RECEIVER


VSX-1016V-K
VSX-1016V-S
VSX-1016TXV-K
VSX-80TXV
VSX-80TXV-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model                Type                  Power Requirement               Remarks

VSX-1016V-K       HYXJ5             AC 220 V to 230 V

VSX-1016V-S       HYXJ5             AC 220 V to 230 V

VSX-1016TXV-K     KUXJ              AC 120 V

VSX-80TXV         KUXJCA            AC 120 V

VSX-80TXV-S       KUXJCA            AC 120 V




     For details, refer to "Important Check Points for good servicing".




                                                                          T-IZS SEPT. 2006 printed in Japan
                1                                  2                                 3                                 4

    SAFETY INFORMATION

A


    This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
    yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
    to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
    This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
B
    cause cancer, birth defects or other reproductive harm.
                                                                                 Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or            (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
