Image preview - the first page of the document
>> Download hfe_pioneer_vsx-1017av_1017txv_90txv_service_en documenatation <<Text preview - extract from the document AUDIO/VIDEO MULTI-CHANNEL RECEIVER VSX-1017AV
STANDBY/ON PHASE
CONTROL
EON PTY LISTENING MULTI CH SIGNAL SB ch SOUND
MODE SEARCH MODE DVD/LD TV/ SAT DVR/ VCR 1 DVR/ VCR 2 VIDEO/GAME CD CD-R / TAPE / MD FM/AM USB iPod IN SELECT PROCESSING RETRIEVER
MULTI JOG ENTER MASTER
VOLUME
S-VIDEO VIDEO/GAME INPUT USB MCACC
VIDEO L AUDIO R DIGITAL IN SETUP MIC
PHONES
ORDER NO.
SYSTEM TUNING/ TUNER
SETUP RETURN TONE STATION EDIT SPEAKERS
MULTI JOG
RRV3599
VSX-1017AV-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-1017AV-K
VSX-1017AV-S
VSX-1017TXV-K
VSX-90TXV
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-1017AV-K HYXJ5 AC 220 V to 230V
VSX-1017AV-S HYXJ5 AC 220 V to 230V
VSX-1017TXV-K KUXJ AC 120 V
VSX-90TXV KUXJ/CA AC 120 V
For details, refer to "Important Check Points for good servicing".
T-FZV MAY 2007 printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
