Image preview - the first page of the document



>> Download hfe_pioneer_vsx-32_33_service_en documenatation <<

Text preview - extract from the document

                                                                                                         ORDER NO.
                                                                                                      RRV4087
                                                               VSX-33

AUDIO/VIDEO MULTI-CHANNEL RECEIVER


VSX-33
VSX-32
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model               Type                 Power Requirement                             Remarks

 VSX-33           UXJCB           AC 120 V

 VSX-32           UXJCB           AC 120 V




This service manual should be used together with the following manual(s).
            Model No.              Order No.                                Remarks

 VSX-LX53/SYXJ5                   RRV4133



For SPECIFICATIONS and PANEL FACILITIES, refer to the operating instructions.




PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936


                                                                                      K-ZZZ JUNE 2010 Printed in Japan
                 1                                     2                                             3                                                    4

    SAFETY INFORMATION

A


    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely,
    you should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
B   This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive
    harm.
                                                                         Health & Safety Code Section 25249.6 - Proposition 65


    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or                      (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
