Image preview - the first page of the document
>> Download vsx417k documenatation <<
Text preview - extract from the document
VSX-417
MULTI JOG
ENTER
PHASE
CONTROL
PHASE DIALOGUE AUTO SURR/ STEREO/ ADVANCED
CONTROL ENHANCEMENT DIRECT DVD/LD TV/SAT DVR/VCR VIDEO/FRONT AUDIO CD CD-R / T A P E / M D USB FM AM AUX F.S.SURR STANDARD SURROUND
LISTENING MODE
SOUND EON VSB MASTER
RETRIEVER MODE MODE TONE VOLUME
STANDBY/ON
PHONES SIGNAL
SELECT
PTY
SEARCH
TUNER
EDIT
QUICK
SETUP
MULTI JOG
SETUP RETURN
DOWN UP
ORDER NO.
RRV3560
VSX-417-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-417-K
VSX-417-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-417-K MYXJ5 AC 220 V to 230 V
VSX-417-S MYXJ5 AC 220 V to 230 V
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
T-ZZK MAR. 2007 printed in Japan
Downloaded from www.Manualslib.com manuals search engine
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
