Image preview - the first page of the document



>> Download VSX-54_56_RRV2990 documenatation <<

Text preview - extract from the document

                                                                                                         ORDER NO.
                                                                                                       RRV2990
                                                                VSX-56TXi

AUDIO/VIDEO MULTI-CHANNEL RECEIVER


VSX-56TXi
VSX-54TX
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model             Type                    Power Requirement                             Remarks

 VSX-56TXi       KUXJ/CA           AC120V

 VSX-54TX        KUXJ/CA           AC120V




   For details, refer to "Important symbols for good services".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2004
                                                                                        T-ZZV JULY 2004 printed in Japan
                 1                                            2                                   3                                  4

    SAFTY INFORMATION

A


    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
    WARNING
B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
                                                                              Health & Safety Code Section 25249.6
