Image preview - the first page of the document
VSX-515_RRV3092


>> Download VSX-515_RRV3092 documenatation <<

Text preview - extract from the document
                                                                                                                                              AUDIO/VIDEOMULTI-CHANNELRECEIVER



                                                                                                                                                                             MULTIJOG




                                                                                                                                                  ENTER




                                                                          DVD/LD   DVD 5.1   TV/SAT   DVR/VCR   CD   CD-R/TAPE/MD   FM   AM

                                                                                                                                                                                  MASTER
                                                                                                                                                                                  VOLUME




                                                    STANDBY/ON


                                                                 PHONES



                                                                                                                                                     DOWN                        UP
                                                                                                                                                                                                           ORDER NO.
                                                                                                                                                                                                         RRV3092
                                                                                             VSX-515-K

AUDIO/VIDEO MULTI-CHANNEL RECEIVER


VSX-515-K
VSX-515-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model             Type                    Power Requirement                                                                                                                               Remarks

 VSX-515-K       KUCXJ             AC 120V

 VSX-515-S       KUCXJ             AC 120V




   For details, refer to "Important Check Points for Good Servicing".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2005
                                                                                                                                                                                           ZZK MAR. 2004 printed in Japan
                 1                                            2                                   3                                  4

    SAFETY INFORMATION

A


    This service manual is intended for qualified service technicians; it is not meant for the casual
    do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
    trained to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.
    WARNING
B   This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
    cause cancer, birth defects or other reproductive harm.
                                                                              Health & Safety Code Section 25249.6
