Image preview - the first page of the document
>> Download hfe_pioneer_vsx-516_service documenatation <<
Text preview - extract from the document
AUDIO/VIDEO MULTI-CHANNEL RECEIVER VSX-516
MULTI JOG
ENTER
ADVANCED ST/DIRECT/ SIGNAL SB ch DIALOGUE
STANDARD SURR AUTO SURR DVD/LD DVD 5.1 TV/SAT DVR/VCR CD CD-R/TAPE/MD FM AM TUNING STATION SELECT PROCESSING ENHANCEMENT
LISTENING MODE
ANALOG MIDNIGHT/ MASTER
DIMMER ATT LOUDNESS SPEAKERS VOLUME
STANDBY/ON
PHONES
MUTE
TUNER
EDIT TONE
QUICK
SETUP
MULTI JOG
SETUP RETURN
ORDER NO.
DOWN UP
RRV3329
VSX-516-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-516-K
VSX-516-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWINGMODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-516-K KUCXJ AC 120 V
VSX-516-S KUCXJ AC 120 V
VSX-516-K MYXJ5 AC 220 V to 230 V
VSX-516-S MYXJ5 AC 220 V to 230 V
VSX-516-S MVXJ5 AC 230 V
For details, refer to "Important Check Points for Good Servicing".
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
