Image preview - the first page of the document
>> Download hfe_pioneer_vsx-517_k_s_service_en documenatation <<
Text preview - extract from the document
VSX-517
MULTI JOG
ENTER
PHASE
CONTROL
PHASE DIALOGUE AUTO SURR/ STEREO/ ADVANCED
CONTROL ENHANCEMENT DIRECT DVD/LD DVD 5.1 TV /SAT DVR/ VCR CD CD-R / TAPE / MD FM AM TUNING STATION F.S.SURR STANDARD SURROUND
LISTENING MODE
SOUND MIDNIGHT/ VSB MASTER
RETRIEVER LOUDNESS MODE TONE VOLUME
STANDBY/ON
PHONES SIGNAL
SELECT DIMMER
TUNER
EDIT
QUICK
SETUP SETUP
MULTI JOG
RETURN
DO UP
ORDER NO.
RRV3550
VSX-517-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-517-K
VSX-517-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWINGMODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-517-K KUCXJ AC 120 V
VSX-517-S KUCXJ AC 120 V
For details, refer to "Important Check Points for Good Servicing".
T-ZZK FEB. 2007 printed in Japan
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
