Image preview - the first page of the document



>> Download pioneer_vsx-520-k_820-k_rrv4043_sm_[ET] documenatation <<

Text preview - extract from the document

                                                                                                            ORDER NO.
                                                                                                         RRV4043
                                                                VSX-820-K

AUDIO/VIDEO MULTI-CHANNEL RECEIVER


VSX-820-K
VSX-520-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model            Type                    Power Requirement                                Remarks

 VSX-820-K       CUXCNSM         AC 120 V
 VSX-520-K       CUXCNSM         AC 120 V




      For details, refer to "Important Check Points for good servicing".


PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2010
                                                                                         K-IZK MAR. 2010 Printed in Japan
                 1                                  2                                3                                 4

    SAFETY INFORMATION

A



    This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
    yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
    to properly and safely repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may
    void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
    should not risk trying to do so and refer the repair to a qualified service technician.

    WARNING
B   This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive
    harm.
                                                                         Health & Safety Code Section 25249.6 - Proposition 65

    NOTICE
    (FOR CANADIAN MODEL ONLY)
    Fuse symbols           (fast operating fuse) and/or            (slow operating fuse) on PCB indicate that replacement parts must
    be of identical designation.

    REMARQUE
    (POUR MOD
