Image preview - the first page of the document
>> Download hfe_pioneer_vsx-815-k-s_915-k_service documenatation <<
Text preview - extract from the document
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
MULTIJOG
ENTER
ADVANCED ST/DIRECT SIGNAL
STANDARD SURR /AUTO SURR SELECT DVD/LD TV/SAT DVR/VCR VIDEO CD CD-R/TAPE/MD TUNER AUX
MASTER
LISTENING MODE
VOLUME
INPUT EXTENDED ACOUSTIC
FL DIMMER ATT SPEAKERS MODE EQ VIDEO INPUT MCACC
S-VIDEO VIDEO L AUDIO R DIGITAL IN SETUP MIC
STANDBY/ON
PHONES
BAND
TUNING
/STATION
TUNER
EDIT TONE
QUICK
SETUP
MULTI JOG
SYSTEM
SETUP RETURN
DOWN UP
ORDER NO.
RRV3093
VSX-815-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-815-K
VSX-815-S
VSX-915-K
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-815-K KUXJ/CA AC 120V
VSX-815-S KUXJ/CA AC 120V
VSX-915-K KUXJ/CA AC 120V
For details, refer to "Important Check Points for Good Servicing".
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
