Image preview - the first page of the document
>> Download hfe_pioneer_vsx-817_917v-k-s_service documenatation <<
Text preview - extract from the document
VSX-917V
MULTI JOG
ENTER
PHASE
CONTROL
DIGITAL PRECISION
PROCESSING
PHASE ACOUSTIC AUTO SURR/ STEREO/ ADVANCED
CONTROL EQ DIRECT DVD/LD TV/SAT DVR / VCR VIDEO/FRONT AUDIO CD CD-R / T A P E / M D USB FM AM AUX F.S.SURR STANDARD SURROUND
LISTENING MODE
SOUND MIDNIGHT/ SIGNAL MASTER
RETRIEVER LOUDNESS SELECT TONE VOLUME
STANDBY/ON VIDEO INPUT MCACC/
USB
ORDER NO.
VIDEO L AUDIO R DIGITAL IN AUDIO IN
PHONES PTY TUNING/ TUNER
SPEAKERS SEARCH STATION EDIT SETUP RETURN
MULTI JOG
DOWN UP
RRV3559
VSX-917V-K
AUDIO/VIDEO MULTI-CHANNEL RECEIVER
VSX-917V-K
VSX-917V-S
VSX-817-K
VSX-817-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model Type Power Requirement Remarks
VSX-917V-K MYXJ5 AC 220 V to 230 V
VSX-917V-S MYXJ5 AC 220 V to 230 V
VSX-817-K MYXJ5 AC 220 V to 230 V
VSX-817-S MYXJ5 AC 220 V to 230 V
For details, refer to "Important Check Points for Good Servicing".
1 2 3 4
SAFETY INFORMATION
A
This service manual is intended for qualified service technicians; it is not meant for the casual
do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
B This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to
cause cancer, birth defects or other reproductive harm.
